Static Dissipative Vinyl Floor Tile for Electronics Conductive Tile Flooring

Product Description

ESD Vinyl Flooring Tiles Anti Static PVC Floor Tiles 600mmx600mmx2mm Product Description
Electrostatic Discharge (ESD) flooring is also known as anti-static flooring, comes with anti-static performance (static-dissipative or conductive), and protects electronics from damage caused by static electricity.
The ESD flooring tiles are of high density, non-porous natural organic tile visual. They're manufactured by an extrusion process, mixing and pressing the pure PVC granules with carbon (graphite) fibers, and non-toxic color particles under proper pressure and temperature. Conductive elements are distributed throughout the flooring material, Thus they give ESD floors electrical conductivity, create an electrical pathway from the walking surface to the ground, and guarantee a permanent ESD performance. ESD vinyl flooring tiles are the choice of professionals for controlling electrostatic discharge in clean rooms, electronics manufacturing, computer rooms, repair facilities, or anywhere static-sensitive components are being used or manufactured.
ESD Tile SizesThe popular and standard size is 600×600mm, 610x610mm, 900×900mm.
The thickness of the tiles is mainly 2.0mm, 2.5mm, 3.0mm.
Weight: 3980g/m2 (2.0mm Thickness)
Detailed Photos


Product Parameters

Item	Standard	Data
Electrical Resistance(Ω)	SJ/T11236-2001	Conductive	Dissipative
		2.5 x 10E4 - 1.0 x 10E6 ohms	1.0 x 10E6 to 1.0 x 10E9 ohms
Dimensional(%)	ISO 23999:2018	0.05
Stating Voltage	SJ/T11236-2001	50 V	100 V
Static Decay(s)	GJB2605-1996	≤ 2
Wear Resistance	EN 660-2:1999	Class P
Fire Resistance	EN13501-1:2007	Bfl-s1
Radiant Flux(W/cm2)	ASTM E648-2017	≥ 1.1
Slip Resistance Wet	EN13893	≥ 0.3
Residual Indentation(mm)	ISO 24343-1:2002	≤ 0.15-0.03mm
Color Fastness	ISO 105B 02	≥ 6
Chemical Products Resistance	EN ISO 26987:2012	OK
Migration of Certain Elements	EN 71-3:2013	OK
RoHS Directive(%)	EN 62321	0.003
TVOC After 28 Days(μg/m³)	ISO 16000-3	< 10 μg/m³

Application
ESD vinyl flooring tiles are the choice of professionals for controlling electrostatic discharge in clean rooms, electronics manufacturing, computer rooms, repair facilities, or anywhere static-sensitive components are being used or manufactured.
Installation Instructions
Installation:
Installation should be carried in accordance with local standards. Subfloor to be smooth, hard, clean and dry prior tolaying.Where applicable the subfloor must incorporate an effective Damp Proof Membrane. The material must be allowed toacclimatize 24 hours before installation in a room temperature of between 18 - 24 degree.
We also have :
Sports floor
Floor Install Accessories:
Product Advantages
Our Advantages 1. We have full-automated production lines to ensure higher production efficiency.
2. We have patents on production process optimization.
3. Tempering is a process of heat treatment. We have the longest tempering production lines in China which control dimensional stability effectively.
4. We have an independent testing laboratory with appropriate testing instruments and equipment.
5. Testing and calibration are performed using USA/EU/JAPAN/CHINA standard methods. So we can produce ESD vinyl flooring products in compliance with different standards.
6. We use DOTP plasticizer for ESD PVC flooring.
Dioctyl terephthalate commonly abbreviated DOTP or DEHT. It is a non-phthalate plasticizer that is considered safer than ortho-phthalate plasticizers due to its excellent toxicological profile.
7. The product does not contain carcinogens such as benzene and heavy metals such as lead.

Company Profile
Kama International Trade & technology co., ltd was founded in 2005, we specializing in laminate, PVC vinyl flooring, SPC flooring, Homogeneous, Heterogeneous pvc floor and Wall Panel. With 2 manufacturing quarters located in Jiangsu and Zhejiang Province, products capacity over 7000000sqms each year. Our products has been exported to more than 50 countries and regions all over the world and get great reputation for our high quality products and very good service.
