Crane Components Crane End Carriages

Product Description

Specifications
1. Manufacturer Bridge Crane/Gantry Crane End Truck End Carriage Customization
2. For overhead crane, gantry crane
Manufacturer Bridge Crane/Gantry Crane End Truck End Carriage Customization, Electric End Carriage Steel Crane Wheels For Overhead Crane 1ton ~ 100ton.
1~100T crane trolley-end carriage
Independently driven. For single girder & double girder.
Low repair rate.
Tough material, high safety.
Nante has successfully developed crane kits systems for all kinds of overhead cranes. We are committed to provide our quality service though operational excellence and technology improvement.
A wide range of Crane End Carriage is available for customers' choice. They are designed for single girder crane, double girder crane range from 1~50ton(standard), other capacity can be customized.
With the backup of high quality manufacturing facilities and solid technological strength, we have been pursuing for nearly two decades the service principle of "quality first", providing qualified goods for customers in South America, South Asia, Europe, Middle East, etc,
Application
End carriage is applicable for wide range of cranes, such as workshop overhead bridge crane, gantry crane, etc. We are committed in providing our customers with quality and customized service.
Design Feature
High strength profile with reinforced plate inside
45# steel wheel group, HRC45-48.
Self-lubricating bearing
Soft start motor from Taiwan brand.
Modular design

Suitable Crane	Travel Speed V (m/min)	Power (KW)	Wheel Dia.D (mm)	S1(mm)	S2(mm)	W1(mm)	W2(mm)	B(mm)	H(mm)
1t2t/5.5m-11.5m	18	0.3X2	144	2000	1760	500	410	150	200
1t2t/12m-16.5m	18	0.3X2	144	2500	2260	500	410	150	200
3t/5.5m-11.5m	18	0.3X2	144	2000	1760	500	410	150	250
3t/12m-16.5m	18	0.4X2	144	2500	2260	500	410	150	250
1t2t3t/17m-22.5m	18	0.4X2	144	3000	2700	550	440	150	250
1t2t/23m-25.5m	18	0.4X2	144	3500	3200	600	510	150	250
5t/5.5m-11.5m	18	0.4X2	168	2000	1600	600	510	150	250
5t/12m-16.5m	18	0.4X2	168	2500	2100	600	510	200	250
5t/17m-22.5m	18	0.4X2	168	3000	2600	650	560	200	250
3t/23m-25.5m	18	0.4X2	168	3500	3100	650	560	200	250
10t/5.5m-11.5m	19	0.75X2	208	2000	1600	600	510	200	250
10t/12m-16.5m	19	0.75X2	208	2500	2100	650	560	200	300
10t/17m-22.5m	19	0.75X2	208	3000	2600	650	560	200	300
10t/23m-25.5m	19	0.75X2	208	3500	3100	650	560	200	300
16t/5.5-16.5m	20	1.1X2	238	2500	2060	700	600	200	300
16t/17m-22.5m	20	1.1X2	238	3000	2560	750	650	200	300
10t/23m-25.5m	20	1.1X2	238	3500	3060	700	600	200	300
20t/5.5m-16.5m	19	1.5X2	238	2500	2060	950	800	200	350
20t/17m-22.5m	19	1.5X2	238	3000	2560	950	800	200	350
