| CPU Compatibility | Intel Full series |
| | AMD AM4/FM2+/FM2/FM1/AM3+/AM3/AM2+/AM2 |
| TDP | 230W |
| Overall Dimension | 135(L)X105(W)X160(H)mm |
| Heatsink Material | Aluminum |
| Heat Base Material | 55X35mm Aluminum Base with HDT(Heat pipes Direct) |
| Heat Pipes | 6X6mm Copper powder heat pipes U type |
| Surface Treatment | Anti-oxidation Protective Layer |
| Weight/Loading | 910g / 605*395*260mm /10Pcs /CTN |
| RGB Version | AURA 5V 3Pin addressable |
| Fan Dimension | 120×120×25mm |
| Included Fans | 2pcs |
| Fan Speed | 1000~2000±10%RPM |
| Max. Air Flow | 72CFM |
| Max. Static Pressure | 2.36mmH2O |
| Noise | 8~29.1dB(A) |
| Rated Voltage | 12VDC |
| Operating Voltage | 8~13.2VDC |
| Started Voltage | 7.5VDC |
| Rated Current | 2*0.22~0.39A(Fan Moto)+2*0.3A(RGB)+0.2A(RGB) |
| powder Input | Single fan:4.7W+1.5W; Top guard RGB: 1.5W |
| Bearing Type | Hydraulic Bearing |
| | |
| Fatures | Universal metal EasySET Pro bracket |
| | Single tower dual fan setting |
| | Close Air channel design |
| | Two full function PWM Fan |
| | SilentPro Blades design with Corona LED Frame |
| | Notice: Include RGB controller |
