Metal Case Constant Current LED Driver Waterproof Power Supply

Product Description

Metal Case IP67 500mA 700mA 1050mA Constant Current Led Driver 40w ac/dc Waterproof Power Supply
Product Description Input:100-240VAC 50/60Hz
Output Voltage: 12V-48V DC
Rated Power: 40W max
Approvals: UL/CUL/CB/FCC/TUV
Features :
1. Univeral AC input/ Full range
2. Energy efficiency level VI
3. Leakage Current: <2.5mA
4. Extremely low leakage current
5. Protection:Over load/Over voltage/Short circuit
6. Life Warranty: 3 years
Applications:
- LED Street Light
- LED Wall washer light
- Outdoor lighting

Model:	YSCL40-0800500	YSCL40-0570700	YSCL40-0381050	YSCL40-0281400
Power:	40W Max
Input:	AC100-240V
Rated Current:	500mA	700mA	1050mA	1400mA
Voltage Range:	40-80V	28-57V	16-68V	14-28V
Inrush Current:	65 Amps max. at 230VAC/50Hz
Leakage Current:	<2.5mA
No Load Power Consumption :	<0.5W
Protections:	Short Circuit /Over Current /Over Voltage/over temperature protection
Working TEMP.:	-20°C-50°C
EMC standards:	ESD Test:IEC 61000-4-2 RS Test:IEC 61000-4-3 EFT/B Immunity Test:IEC61000-4-4 Surge Immunity :IEC61000-4-5 Conduted RF Immunity: IEC 61000-4-6 Power frequency magnetic field:IEC 61000-4-11 Voltage dips and interruptions,100% reduction: IEC 61000-4-11 Voltage dips and interruptions,30% reduction: IEC 61000-4-11
Dimension:	139*49*37mm
Packing:	1PC/PE BAG+INNER BOX, 50PCS/CTN, CAN BE CUSTOM
