240L -2000L Pressurized Flat Plate Solar Water Heater with Stainless Steel Coil Price

Product Description

240L -2000L Pressurized Flat Plate Solar Water Heater with Stainless Steel Coil Price
Company Profile Sola Solar has been engaged in the field of solar thermal industry for 22 years since 1999 and has accumulated a lot of industry experience 2008 research and development of non-power solar system, has a number of invention patents. For several years, we have been setting national and industry standards for solar systems in China Quality is ingrained in everything we do, and we also customized produce. We know that solar system is a very difficult thing to do well, we Revere nature. We provide thousands of project cases for key projects and high-end customers in China, all of which are in reliable operation We are a small enterprise from designation, production, installation, operation and maintenance, we will cherish every inquiry, every service.
Product Description
Sola Solar Pump free solar water heater is Open water tank for heat storage, closed coil for heat exchange and water intake. Sola Solar 20 second rapid heat exchange technology is adopted. The hot water is ready to use, and the water quality is fresh. The hot water pressure comes from the municipal cold water pressure, which matches with the cold water. It is simple to adjust the water temperature. The pressure is surging, the water volume is sufficient, and the use experience is good.
Sola Solar water heater is different from others.
No.1
The end cover of the solar water tank adopts flange connection, which can be opened and maintained at any time, making it safer and more convenient to use.
No.2
The solar energy solar heater adopts a modular design, and the water tank can be expanded to meet the needs of customers with large water consumption and many water usage points.
No.3
The rapid heat exchange technology developed by Sola Solar, cold water flows through the stainless steel bellows heat exchanger for 20 seconds to quickly turn into hot water. The water quality is fresh, and it can be used as kitchen water.
Our main products are: pump free solar water system, household solar water heater, commercial solar heating system, integrated pipeline, hot water unit and other related products.
We also have finished thousands of project cases for key projects and high-end customers in China, all of which are in reliable operation. Main project achievements are: Abidjan Elite School in Ivory Coast, Congo Province Comprehensive Hospital Project, Sri Lanka Hospital, Niger Benin Project, Cambodia Projects; Central Academy of Drama, Beijing University of Posts and Telecommunications, Daxing International Airport China Southern Airlines etc.
Product Parameters

Product name	215L Flat Plate Solar Water Heater	240L Flat Plate Solar Water Heater
Type of solar water heater	Pump-free Compact Type	Pump-free Compact Type
Model 1 (Non-freeze 0ºC )	PFSLP-215/4.0/0	PFSLP-240/4.0/0
Model 2 (Antifreeze -20ºC )	PFSLP-215/4.0/-20	PFSLP-240/4.0/-20
Types of solar water heaters	Pressurized	Pressurized
Collector	Non freeze and Antifreeze Flat plate collector	Non Freeze and Antifreeze Flat Plate Collector
Absorber surface	Whole board blue film	Whole board blue film
Core runner	copper pipe	copper pipe
Collector Specifications	1000*2000*80mm	1000*2000*80mm
Number of collectors	2 pieces	2 pieces
Frame material	6063-T5 aluminum alloy	6063-T5 aluminum alloy
Inner tank material	0.5mm SUS304 stainless steel	0.5mm SUS304 stainless steel
Inner tank diameter	Φ360mm	Φ380mm
Outer tank material	0.4 mm color galvanized steel plate	0.4mm color galvanized steel plate
Outer tank size	Φ460mm	Φ480mm
Insulation material	50mm flame retardant polyurethane foam	50mm flame retardant polyurethane foam
Heat exchanger Material	316l stainless steel, 0.3mm thickness	316 stainless steel, 0.3mm thickness
Cold/hot water port connection	DN32/DN50	DN32/DN50
Product Weight	130kg	132kg
Requirements for roof loads	100kg/m²	100kg/m²
Aperture area	4.0 m²	4.0 m²
Water tank capacity	220L	240L
Weight full	350kg	370kg
Product Size	Length A (mm) 2630	Length A (mm) 2355
	Width B (mm) 2370	Width B (mm) 2678
collector inclination	5°~30°	5°~30°
Min. outdoor temperature	0ºC and -20 ºC	0ºC and -20 ºC
Reserved basic dimensions 'Length*width(mm*mm)	2350*1900	2000*2040

Our Advantages
Application show 1. A hospital in Beijing

In 2018, Beijing Haidian, for 3000 people
Pump free solar collector:96 Sets (403.2 m² in total)	Storage capacity:60ºC hot water 30000 liters in total,
Auxiliary heat source: 4 sets gas boiler	Energy saving: 331772 kWh per day.

2. Beijing University of Posts and Telecommunications

In 2015, Beijing Changping project for 800 students
Pump free solar collector:1057 Sets (44394 m² in total)	Storage capacity:60ºC hot water 32000 liters in total,
Auxiliary heat source: 8 sets gas boiler	Energy saving: 476575 kWh per day.

3. Beijing Daxing Airport dormitory

In 2019, Beijing Daxing, for 1200 people.
Pump free solar collector:600 Sets (2520 m² in total)	Storage capacity:60ºC hot water 45000 liters in total.
Auxiliary heat source: 32 sets gas boiler	Energy saving:270520 kWh per day.

4.Schools in Cote d 'Ivoire

In 2019, Cote d'Ivoire Country, for 1000 students
Pump free solar collector:101 Sets (404 m² in total)	Storage capacity:60ºC hot water 24240 liters in total.
Auxiliary heat source: 15 sets Positive displacement electric heater	Energy saving: 45086 kWh per day.

5.A hotel in Nanjing

In 2021, Nanjing city, for 8000 people.
Pump free solar collector:115 Sets (460 m² in total)	Storage capacity:60ºC hot water 27600 liters in total.
Auxiliary heat source: government heat exchange station.	Energy saving: 51802 kWh per day.

6.A company in Beijing

In 2019, Beijing China, for 322 people
Pump free solar collector:82 Sets (328 m² in total)	Storage capacity:60ºC hot water 24600 liters in total.
Auxiliary heat source: 1 set, government heat exchange station.	Energy saving: 36971 kWh per day.

7. Central Academy of Drama

In 2014, Beijing Changping project for 1200 people
Pump free solar collector:150 Sets (630 m² in total)	Storage capacity:60ºC hot water 45000 liters in total
Auxiliary heat source: 6 sets electric water heater	Energy saving: 45087 kWh per day.

Custom feedback
our team
FAQ 1. What can you buy from us?
Solar Water Heater, Solar water system. Solar collector.
2. What is your Delivery Time?
LCL order/Sample order: 3-7 days.
Full container order:10-15 days.
3. What is your warranty?
3 years after delivery;
4. Can you accept OEM?
YES. will do OEM Based on your requirements.
5. What is your MOQ?
1 set.
6. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
7. What services can we provide?
Accepted Delivery Terms: FOB,CFR,EXW;
Accepted Payment Currency: USD, EUR, CNY;
Accepted Payment Type: T/T, L/C;
Language Spoken: English, Chinese.
