Lty-680 Servo Plastic Injection Molding Machine for PP PE
| US$15,800.00 | 1 SET (MOQ) |
Basic Info.
Model NO.
LTY-680
Type
Plastic Product Injection
Structure
Horizontal
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Clamping Way
Hydraulic & Mechanical
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008, GMP, QS
Transport Package
Wrap Film Packing Into The Container
Specification
68T
Trademark
LOYALTY
Origin
China
HS Code
8477101090
Production Capacity
1000sets/Years
Product Description
| SPECIFICATION | LTY680 | |||
| A | B | C | ||
| INJECTION UNIT | ||||
| SCREW DIAMETER | mm | 26 | 30 | 32 |
| SCREW L/D RATIO | L/D | 25.4 | 22 | 20.6 |
| SHOT VOLUME(THEORETICAL) | cm3 | 67.6 | 90 | 102 |
| INJECTION WEIGHT(PS) | g | 61.4 | 82 | 93 |
| INJECTION RATE | g/s | 55 | 73 | 83 |
| INJECTION PRESSURE | MPa | 227 | 170 | 150 |
| SCREW SPEED | rpm | 195 | ||
| CLAMPING UNIT | ||||
| CLAMP FORCE | kN | 680 | ||
| OPEN STROKE | mm | 280 | ||
| SPACE BETWEEN TIE BARS(W*H) | mm | 310x310 | ||
| MAX.MOULD HEIGHT | mm | 320 | ||
| MIN.MOULD HEIGHT | mm | 100 | ||
| EJECTOR STROKE | mm | 80 | ||
| EJECTOR FORCE | kN | 28 | ||
| OTHER | ||||
| MAX.PUMP PRESSURE | MPa | 16 | ||
| PUMP MOTOR POWER | kW | 7.5 | ||
| HEATING POWER | kW | 6.8 | ||
| MACHINE DIMENSION(L*W*H) | m | 3.65x1.13x1.73 | ||
| OILTANK CUBAGE | L | 135 | ||
| MACHINE WEIGHT | t | 2.5 | ||
