N40b IP66 Industrial PDA with Barcode Scanner NFC Reader for Data Capture

Product Description

We are a leading PDA manufacturer with more than 15 years of experience and with advantage of free SDK provided, professional technical team support and CE Rohs certificate
1) Default Configuration: Wifi + BT + 4G (FDD / TDD-LTE) + Phone + GPS + 8M Camera + Google Player Store 2) 1D, 2D, NFC,are optional 3) Compact And Portable Ergonomic Design With Wrist Strap 4) Safedroid OS (Android 10.0) Highly Optimized Android Operating System. 5) 8.0M Mega Pixel Rear Camera, 5MP front Camera 6) High Capacity 4500mAh Large Capacity Battery For Critical Requirements; 7) Pogo Pin Interface For Convenient Charging With Optional Charge Cradle. 8) Industrial Rugged Design, Water-Proof And Protection Grade (IP66); 9)About Shipment: We offer DHL shipping usually, but in emergency, we can choose another shipping option.

Product parameters
Performance
Octa core
CPU	Cortex-A53 Octa-core 64 bit 2.0GHz high performance processor
RAM+ROM	2GB+16GB//4GB + 64GB,please let me know if you need which options
Expand memory	Micro SD(TF) Supports up to 128GB
System	Android 10.0
Data communication
WLAN	Dual-band 2.4GHz / 5GHz, Supporting IEEE 802 a/b/g/n/ac protocol
WWAN	2G: GSM (mobile / Unicom), CDMA (Telecom)
	3G:WCDMA(Unicom),CDMA2000(Telecom), TD-SCDMA (mobile)
	4G: TD-LTE (mobile), fdd-lte (Unicom, telecom)
Bluetooth	Support BT 5.0, transmission distance 5-10m
GPS	Support GPS, Galileo, Glonass, Beidou
Physical parameter
Dimensions	162mm × 71.5mm × 17 (thinnest) mm
Weight	< 300 (depending on equipment function configuration)
Display	4.0 "TN screen, 480×800 resolution
TP	Support multi-touch
Battery capacity	Rechargeable polymer battery (3.8V 4500mAh) removable
	Standby time >350 hours
	Working time > 12 hours
	Support fast charging and removable battery
	Charging time < 2 hours (using standard fast charging power adapter and data cable)
Expansion Card slot	Nano SIM card X2, TF Card X1
Communication interface	Type-C 2.0 USB x 1, support OTG function
	POGO Pin x 1
Audio	Speaker (mono), microphone, receiver
Keypad	25 soft and hard rubber buttons, left button x1, right button x1
Sensor	Gravity sensor, light sensor, distance sensor, gyroscope, electronic compass, vibration motor
Language/input method
Input	English, Pinyin, Five strokes, Handwriting input, Support soft keypad
Language	Multiple Language packs in Simplified Chinese, Traditional Chinese, English, Korean, Japanese, Malaysian etc.

Data collection
Barcode scanning (Optional)
1D Linear scanner	Mindeo SE966 Honeywell N4313
1D Symbologies	Code128,EAN-13,EAN-8,Code39,UPC-A,UPC-E,Codaber,Interleaved 2 of 5,China post 25,ISBN/ISSN,
Barcode Type	Code93, UCC / EAN-128, GS1, DataBar, HIBC, etc
2D Scanning engine	Mindeo E483/ EM6601, Honeywell N6603/ N3603
2D Symbologies	PDF417,Micro PDF417,GS1 Composite,Aztec Code,Data Matrix,QR Code,Micro QR Code,MaxiCode,Hanxin Code,
Camera(standard)
Rear camera	8MP HD camera,Support auto focus, Flash, Anti-shake, Macro shooting
Front camera	5MP pixel color camera
NFC (Optional)
Frequency	13.56MHz
Protocol	Support ISO14443A/B, 15693 agreement
Distance	2cm-5cm
User environment
Operating temperature	-20ºC - 55ºC
Storage temperature	-40ºC - 70ºC
Environment humidity	5%RH--95%RH(no condensation)
Drop specification	6 sides Supports 1.2 meters drops and 30 times to the concrete within the operating temperature
Rolling test	500×0.5m rolling for 6 sides
Protection Sealing	IP66
Accessories
Standard	Adapter, Data cable, Protective film, Instruction manual

High-speed operation performance:
With androd 10.0 operating system, matching 64 bit quad core 2.0GHz high speed processor with prefect compatibility and computing capability, high-speed operating efficiency is suitable for strict application requirement.
Excellent identification ability :
Fully support 1D and 2D barcode scanning,NFC(optional).
Convenient appearance design:
Slim and ergonomics design, it is convenient and comfortable for holding and carrying. 5.0 inch IPS (720x1280) Work even with water or Gloves.
Abundant means of data transportation(option)
2G,3G,4G,Wifi,Bluetooth,etc.
Industrial grade durability:
IP66 industrial grade, solid and light body can bear the height of 1.2m dropping and 1000 times tumbled within the scope of 0.5m. Waterproof,dustproof provide long time using without fatiguet.
HD Camera:
Postposition 8 mega pixel autofocus camera, is convenient for client to collect all kind of images and video.
Multiple extensions:
Support GPS , AGPS and Beidou compass navigation.
Always-available wireless connection:
Supports 802.11 a/b/g/n full-band wireless communications and maintains real-time connection with the system to ensure high efficient operation.
