CNC High-End Milling Machine Horizontal Face Milling Machine

CNC High-End Milling Machine Horizontal Face Milling Machine

US$12,580.00
1-4 Sets
US$11,000.00
5+ Sets

Basic Info.

Model NO.
XD2010
Type
Worktable Milling Machine
Object
Sheet
Structure
Cantilevered
Milling Cutter Type
Cylindrical Milling Cutter
Milling Cutter Structure
Inlaid Tooth
Controlling Mode
Program Control
Automatic Grade
Semiautomatic
Precision
Normal Precision
Certification
CE, ISO 9001
Condition
New
Milling Head Vertical Stroke
1000 mm
Table Size
800*2200mm/800*3000mm
Table Feed Speed
Frequency
Milling Head Travel
350 mm
Power of Spindle Motor
7.5 Kw
Power of Table Motor
4.0 Kw
Milling Head Vertical Motor Power
1.1 Kw
Weight
5600 Kg
Trademark
NORTH CRAFTSMAN
Origin
China
HS Code
8459699000
Production Capacity
100 Sets/Year

Packaging & Delivery

Package Size
380.00cm * 560.00cm * 220.00cm
Package Gross Weight
4500.000kg

Product Description


Face milling machine Single column milling machine has a wide processing range and is suitable for end face cutting of metal materials such as castings and steel parts. It is widely used in machinery manufacturing.
It is especially suitable for the plane milling of the mold industry and the plastic mold frame frame.
It can process the special surface of milling, drilling and boring on both ends of the long workpiece.
Product Parameters

Specification
Unit
XD2010
XD3010
Table travel
mm
2000
3000
Milling head vertical stroke mm 1000
Table size
Length
mm
2200
3200
Width
mm
800
No. of T-slots
mm
5
Width of T-slots
mm
22
Table feed speed
Feed
mm/min
Frequency
Rapid travel
mm/min
Frequency
Spindle taper

7:24, ISO50
Spindle speed step
r/min
75/105/150/210/300/420
spindle swivel angle

±35°
Milling head travel
mm
350
Power of spindle motor
kw
7.5
Power of table motor
kw
4.0
Milling head vertical motor power Kw
1.1
Dimensions mm 3700*2350*2100 5200*2350*2100
weight Kg 4300 5500

About Us

Certificate display

Visiting customers

Why Choose Us

Packaging & Shipping

FAQ

1. What is your minimum order quantity and warranty?
MOQ is one set, and warranty is one year.
2. Can we pay by L/C or others ?
Yes ,you can make the payment by T/T , l/C etc.
3. What is your payment terms ?
30% down-payment after contract ,and 70% payment before shipment,
Meanwhite it can be discussed according to your situation.
4.When is the delivery time?
The delivery depends on different machines with different configurations.
Please contact us to confirm it is in stock or not.
5. How to handle the warranty period?
During the warranty period, we will provide free replacement parts (EXW)
which are easy damaged.
If the machine problem is not belonging to our machine quality problems,
when the buyer needs us send engineers to give repairing service, we charge
the appropriate cost.
6.Can your company send the technical personnel to our company and direct our workers for free?
When the machine arrive the buyer's installation site, we timely send mechanical and electrical
engineers to install according to the buyer's schedule, the buyer undertakes board and lodging
of personnel abroad in the process of installation, and also USD50.00-100.00 per day per person.
The seller will cooperate with the buyer to deal with visa and installation preparation before
going abroad.
