New Farming Factory Agricultural Machinery Tractor Three Point Mounted Middle Duty Offset Disc Harrow

New Farming Factory Agricultural Machinery Tractor Three Point Mounted Middle Duty Offset Disc Harrow

US$350.00-750.00 1 Set (MOQ)

Basic Info.

Model NO.
1BJX-2.4
Farming Policy
Dry Cultivating Machinery
Power Source
Tractor
Operation
Soil Preparation Machinery, Movable Operation
Traction Type
Hanging
Drive Type
Chain Drive
Arbor Configuration
Horizontal Axis
Certification
ISO9004:2008;SGS
Color
Yellow
Warranty
One Year
Working Width(M)
2.4
Working Depth(mm)
140
No. of Discs(PCS)
22
Disc Diameter(mm)
560
Weight(Kg)
604
Tractor Power(HP)
65-75
Material
65 Mn Spring Steel
Transport Package
Iron Cage or as Your Request
Specification
65 Mn spring steel
Trademark
TIANSHENG brand
Origin
Shandong Province, China
HS Code
84295212
Production Capacity
2000

Product Description

Product Description
SHANDONG TIANSHENG MACHINERY SCIENCE AND TECHNOLOGY CO.,LTD
------The drafting Unit of the Chinese Standard For Disc Harrows And Disc Ploughs


The series Middle-duty Disc Harrow frame are made of qualified steel tube, Their structures are simple and reing into the soasonable, strong and durable, convenient to operate, easy to maintain and efficient in pulverizing and penetratil and leaves the land with a smooth, even tilth. All these satisfy the agricultural requirements of intensive cultivation.
The 1BJX series suspension Middle-duty Disc Harrow's front and rear gangs are all assembled with scalloped disc, could be used with from 35HP to 80HP type tractors.
The 1BJX series Middle-duty Disc Harrow are suitable for pulverized and loosening clods after ploughing and for planning the land before sowing on cultivated land. The machines can make soil and fertilizer mix up, and clear away the stump of plants on light or medium soil and preparing seed bed for planting.
Model Unit 1BJX-1.6 1BJX-1.8 1BJX-2.0 1BJX-2.2 1BJX-2.4 1BJX-2.5
Working width m 1.6 1.8 2.0 2.2 2.4 2.5
Working depth mm 140 140 140 140 140 140
No. of discs pcs 14 16 18 20 22 24
Disc diameter mm 560 560 560 560 560 560
Weight kg 353 390 434 463 604 760
Tractor power hp 35 45 50 55-65 65-75 80

Detailed Photos

Company Profile
After Sales Service
All products enjoy 12 months warranty period. The warranty period is calcualted from the date of bill of lading .For the defect of material or workmanship has occurred in normal operation, The defective parts will be repaired or replaced free of charge. The guarantee parts will be offered to you in two ways.for the urgent request parts, We will ship the spare parts by international courier, The client will assure the courier expense. For the regular claim spare parts, we will ship them together with next order. We provide our clients with genuine spare parts with the highest quality,exact fitness .If needs,please submit your spare parts request to us,and list products name ,description of required parts.we guarantee that your request will be handled quickly and appropriately. We can also provide training services to different users. FAQ
1.Q: Full price list for these products
A: If you need the price list for these products, please notify the product model so that I can quote you accordingly. Please understand we have a very wide product range, we don't usually offer full products price list.
2. Q: Business terms
A: Shipment time: 25-40days after your payment
Shipment: By sea
Loading port: Qingdao port, China
Destination port: ...To be advised
Payment: T/T, L/C
Warranty: 1 year
3.Q:How can I order from you?
A: Please send us your enquiry list; we will reply you within two working days.
4.Q:If the finger I look for are not in your catalogue, what should I do?
A: We can develop it according to your drawing or sample.
