Optical Fiber Tip Endface Angle Polish Processing Angle-Polished Lensed Fiber

Product Description

Angle-polished Lensed Fiber:
Angle-polished lensed fiber is produced by precision polishing techniques to abtain different angles tip,which mainly to reduce the light return or change the optical transmitted direction.
Product Application:
-Mainly used for laser coupling.
-PLC device coupling.
-Side pupm optical fiber combiner.
-Endoscope illumination.
Product Features:
-3V TECHNOLOGY has unique fiber polishing techniques to produce angle tip as high as to 75 degree,and with different coating design,we can satisfy most of customer requirement.
-±0.2 degree polishing angle precision at best.
-Super clean tip finishing surface.
-AR/Hi-reflection coating.

Bare Fiber Coating
Bare Fiber Coating means laying optical thin film on the bare fiber end face to increase light transmission or reflection.
3V TECHNOLOGY succeed in polishing bare fiber without any epoxy and coating optical precision thin film to the fiber tip,which improve the product quality significantly.
Product Application:
-Fiber laser pump diode coupling
-High power laser processing flexible transmission
-Medical laser equipment coupling transmission
-Fiber optic Sensor(Connecting Photoelectric detector)
Product Features:
-The fiber tip is directly polished without any epoxy in the process,which can aviod laser absorption caused by epoxy residue and reduce the fiber burn rate efficiently.
-High quality fiber tip polishing surface,without scratches and particles on the fiber core.-Coat only on the bare fiber tip(without ferrule&epoxy),which can eliminate film cracking caused by inconsistent thermal expansion coefficients of different substrates under the coating layer.
-Avoid the impact of the ferrule and epoxy on the laser chip at a close distance,effictively reducing COD and chip Contamination.
-Low heat absorption and high laser damage threshold of coating layer,Optical damage threshold(>200MW/cm2,test by quantel USA)

Fiber type	SM/MM/PM or customize
Lensed type	Pinnacle/Conical/Biconical/Rectangular/Wedge
Taper Angle	60°-120°
Radius	R4-R15
Plating Layer	Ni:5-10um Au:0.5-1.0um
Package Type	Glass,Metal sealing
Package Material	Glass,Kovar( 4J29) ,SUS or customize
Connector Type(Optional)	LC/FC/SC/MU/MPO or customize
Hermeticity	1.0E-8ccHe/s;1×10-9M Pa·m3/s
Remark	Customize
