Hot Selling Mini Hydraulic 3/4/5 Axles 80 100 150 Tons Side Dump Tipping Tipper End Rear Dump Bauxite Ore Cargo Sand Stone Mining Transport Semi Trailer

Product Description

Hot Selling Mini Hydraulic 3/4/5 Axles 80 100 150 Tons Side Dump Tipping Tipper End Rear Dump Bauxite Ore Cargo Sand Stone Mining Transport Semi Trailer
Product Instructions
3-4 -5-6 Axles U Box 60-100Tons Rear Dump Tipper Semi Trailer is more and more popular to transport coal, ore, building materials and other bulk and unpacked goods.Bottom and top plate of the dumper trailer would be designed according to international transport standards and different country needs.

Normally we would use 8mm and 6mm thickness plat steel to match the heavy loads' usage, with high resistance, enabling maximum efficiency in any road and weather conditions. The bucket body of 4 Axles U Box 100T Rear Dump Tipper Semi Trailer is made of durable steel, which can withstand the wear and impact of 450HB.

The end cover of 4 Axles U Box 100T Rear Dump Tipper Semi Trailer is connected with an adjustable spring that can be opened and closed from the bottom. 4/5 axles Heavy duty tipper dump trailers are playing more and more roles in west Africa countries, such like Cote d 'Ivoire, Guinea, Ghana and ect.
Product Parameters

Items	QLV9450TDP	QLV9450TDP
Loading Capacity	60 tons	80 tons---100 tons
Axle	3 pieces, 13T FUWA/BPW axle	4 pieces, 13T FUWA/BPW axle
Tyre	12 pieces, 12.00R20	16 pieces, 12.00R20
Dimensions(LxWxH)	9750 to 12000mm x 2500 x 3200mm
Tare weight	10 tons to 12 tons
Axle spacing	1310mm
Rims	8.5-20, 9.0-20
Suspension System	Leaf spring suspension / air suspension
Brake System	Dual line pneumatic brake system with WABCO emergency relay valve
Main Beam	Height 500mm Q345
Chassis	upper 14mm, lower 16mm. Mid web 12mm
Dump Box Thickness	Bottom 8mm Side 6mm
Hydraulic Cylinder	HYVA
Kingpin	2' or 3.5' interchangeable
Landing Gear	28 Tons , Two speed manual operation
Electrical System	1.Voltage: 24v 2. Receptacle: 7 ways (7 wire harness) German standard
Lights and Reflectors	Rear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light
Painting	Shot blast to SA 2.5 Standard prior to application of primer, polyurethane top coat. Total DFT not less than 100μm;Any color will be available
Tool Box	One tool box with a set of standard trailer tools
Spare Tyre Carrier	One piece or two pieces

Product Description
1.The 2-3-4 Axles Dump Trailer is the main product of our factory. It use high stength full thickness Steel, titanium content of 0.98‰, which ensure Beam and frame's Toughness and strength. The strong Loading Capacity, 30-100 Tons Loading Range
Our Advantages
1. Heavy Payload Support: Double-plate main beam for heavy-duty dump trailer, which have stronger carrying capacity, it is not easy to damage. The lattice structure of side borads ensure ort trailers more solid and tough. Besides, stiffeners and unique structural design can help our rear tipper trailers to maximize payload. The widened and thickened leaf spring are also helpful to shock absorption.
2. Durable Hydraulic Cylinder: Famous HYVA Brand. The heavy-duty cylinder with a wider diameter, stronger lifting capacity and higher height, which make sure the lifting more stable and not easy to roll over.

3. Rolled-over supports: We use 4 units vice beam and cross balance beams on the bottom to prevent damage during unloading.

4. Rich experiences: More than 20 years of experiences in producing and exporting trailers and other goods, we have helped hundreds of customers in more than 35 countries in Africa and Southeast Asia.

5. Quality Assurance: We offer 2 years'warranty for chassis frames of our trailers and spare parts support services, would also be responsible for the damage of parts during normal use.

6. Customized Service: We support customized designing and production according to customers'different needs and different road situations to match your usage in local.

Company Profile
Certifications
Packaging & Shipping

FAQ

FAQ

Q1: I want the front two tires are bias tires and the rear 9 tires are radial tires,is it ok ?

A: We can make the tires as your requirement to suit your country's need

Q2: What about your products quality ?

A: Quality is our culture!"Our factory has advanced production technology and management team! Since the Luckin Vehicle factory was established in 2002 to today ,We always attach great importance to quality controlling from the very beginning.

Q3: Can I have samples of this type of Truck and trailer to test the quality ?

A: Yes,you can buy any samples to test the quality,our MOQ is 1 unit

Q4: What others we can do ?

A: According to your order,we will provide the best price and quality trucks and trailers. And we are well capable in offering overseas after-sales service.Besides,we also provide rational packing and shipping program,let shipment save money and security.

Q5: How to guarantee customers get the goods smoothly after they pay ?

A:Don't worry,dear.We have been in this field for 22 years,we will send you production photos once in a while,and we will help you to book the latest ship

Q6: What's the delivery time ?

A:The delivery time is within 15-30 working days after receiving your advance payment

Q7: Can you supply some quick-wear truck or semi trailer parts ?

A:Yes,we can supply truck and semi trailer parts as your request,such as oil filter,fuel filter,air filter, traction,traction pin,balancebeam and semi-trailer plate spring,hanging accessories,turntable,all kinds of trailer brake pads,brake pan,bearings etc

Q8: Do you have any used truck and semi trailer for sale ?

A:We have some trucks and trailers in stock for choice,from 2008-2019 year,the price are favorable. We'll show you our stock if you need.

Q9: Which INCOTERMS 2010 TERMS can we work ?

MAOWO is a professional and sophisticated international player,can handle all INCOTERMS 2010 terms,and we normally work on FOB,CFR,CIF,EXW, DAF

Q 10: What is the warranty of the trucks?

12 months about engine, axle and transimission, some spare part can be 18 months. And we can help you solve every problem about the truck by email and phone whole life.

Q 11: What's your payment terms?

T/T: 30% deposit by T/T, 70% balance should be paid before shipment. L/C: 100% irrevocable Credit of Letter. Sight L/C
