13.56MHz MIFARE NFC Tags Smart Card Reader Bluetooth Access Control Card Reader ACR1311u-N2)

Product Description

13.56MHz MIFARE NFC Tags Smart Card Reader Bluetooth Access Control Card Reader ACR1311U-N2) Detailed Photos ACS Designated Supplier Feature
USB 2.0 full speed interface Bluetooth 4.0 smart interface Plug and Play - CCID support brings utmost mobility USB Firmware Upgradeability Smart Card Reader Application Programming Interface Supports Android™ 4.3 and above Supports iOS 5.0 and later Built-in Peripherals

Product Parameters

Physical characteristics
Dimensions	60mm(L)×47.98mm(W)×12mm(H)
Weight	20g
Color	White
Bluetooth Interface
Protocol	Bluetooth Smart (Bluetooth Low Energy /Bluetooth 4.0)
Power Source	Rechargeable Lithium-ion Battery (Charging through USB)
Speed	1Mbps
USB Host Interface
Protocol	USB Full Speed
Type	Four Line:+5V,GND,D+ and D-
Connector Type	Micro USB
Power Source	From USB Port
Speed	USB Full Speed (12 Mbps)
Cable Length	1 m (Datachable)
Firmware	Upgradeable through USB Interface
Contactless Smart Card Interface
Standard	ISO 14443 Type A,MIFARE,DESFIRE
Protocol	ISO 14443 T=CL for ISO14443-4 compliant cards, and T+CL Emulation for MIFARE Classic 1k/4k and NFC tags
Operating Frequency	13.56MHz
Operating Distance	Up to 25mm(depending on tag type)
Smart Card Read/ Write Speed	106Kbps,212Kbps,424Kbps
Antenna Size	28.00mm×32.00mm
Built-in Peripherals
LED	2bi-color, Red and Blue,Red and Green
Buzzer	Monotone
Operating Conditions
Temperature	0ºC-50ºC
Humidity	Max.90%(non-condensing)
MTBF	500,000 hrs
Application Programming Interface
PC-link Mode	PC/SC CT-API(through wrapper on top of PC/SC)
Certifications/Compliance	EN60950/IEC 60950,ISO 14443,USB Full Speed,Bluetooth Smart, PC/SC,CCID,RoHS 2, REACH, Microsoft® WHQL
Device Driver Operating System Support	Windows®ME,Windows®98,Windows®2000,Windows®XP,Windows®Vista, Windows®7,Windows®8,Windows®8.1,Windows®10,Windows®Server2003, Windows®Sever2008,Windows,®Sever2008R2,Windows ®Sever2012, Windows®Sever2012R2,Linux®,Mac OS®, Android, iOS

Company Profile Certifications Customer Reviews
Packaging & Shipping
After Sales Service
FAQ 1. Are you manufacturer?
Yes, we are manufacturers. We have been in PC/POS/Mobile Payment product & Solution for Eight years. We can provide OEM / ODM customized service according to our customers' various application and demands.
2. Would you provide SDK for me?
Yes, we offer free SDK if you order sample. All the contents in a CD ROM with sample together.
3. What warranty for the products?
According to our warranty policy, we will provide 12 months warranty time from the shipment date for our all products (Excluded the consumable parts). As for the mass order, we will provide certain proportion spare parts or RMA machine for local service.
4. What is the minimum order?
We accept one piece for standard products. If require OEM, will see detailed requirements and confirm MOQ to you from our sales department.
5. Can we get the free sample?
Sorry, generally we would not provide the free sample. If the customer confirm the specification and price, they can order the sample firstly for the testing and evaluation. When they place the mass order, we can return the sample cost to the customers.
6. Do you accept Paypal?
Yes, we accept paypal. Besides, we accept Western Union, T/T, L/C Secure payment and so on.
7. What's the delivery time?
Generally, sample can be shipped in 2-3 working days after payment. For quantity, theleading time will be 1-4 weeks depend on exact quantity.

8.Which way to deliver the goods?
By Express: DHL UPS TNT FEDEX or ARAMEX EMS E-packing.
By Sea: Inform us the Sea Port to check which ship line.
By Air: Inform us the Airport to check which flight.
Or pick up by the customers.

9. What the after sale service?
a. Our all products will provide 12 months warranty;
b. Enough stock spare parts for guarantee;
c. Professional engineers provide 7*24 online service; If required, our engineers can provide local service in field;
d. As for the returned failure products, we will fix it and return to the customers in one week after we received it;
