Ee80 Ee100 Ee125 Ee150 Ee200 for Conveyor Belts
| Negotiable | 5 Tons (MOQ) |
Basic Info.
Model NO.
EE80- EE600
Material
100% Polyester
Pattern
Plain
Structure
Fabric Form
Style
Dipped
Type
Canvas Fabric
Width
Make to Order
Feature
High Tensile Strength
Usage
Conveyor Belt
Delivery Time
Within 20 Days
Items
Ee80-Ee500
Transport Package
in Rolls
Specification
EE80-EE600
Trademark
HL GROUP
Origin
China
HS Code
59100000
Production Capacity
50000 Per Year
Product Description
EE Fabric is suitable for long distance conveying with high load,speed and impact ,especially for wet environment.
EE Fabric characteristic as below:
1. High tensile strength
2. Good shock resistance
3. Good heat resistant
4.Low elongation and low shrinkage
5.Excellent adhesion
Specification:
Property | Unit | EE80 | EE100 | EE125 | EE150 | EE200 | EE250 | EE300 | |||||||
| warp | weft | warp | weft | warp | weft | warp | weft | warp | weft | warp | weft | warp | weft | ||
| Breaking force | N/cm | ≥1050 | ≥450 | ≥1250 | ≥500 | ≥1450 | ≥600 | ≥1850 | ≥650 | ≥2300 | ≥750 | ≥3300 | ≥900 | ≥3500 | ≥900 |
| Elongation at break | % | ≥14.0 | ≤45.0 | ≥14.0 | ≤45.0 | ≥14.0 | ≤45.0 | ≥14.0 | ≤45.0 | ≥14.0 | ≤45.0 | ≥14.0 | ≤45.0 | ≥14.0 | ≤45.0 |
| Elongation at 10% load | % | ≤2.0 | ≤2.0 | ≤2.0 | ≤2.0 | ≤2.0 | ≤2.0 | ≤2.0 | |||||||
| HAS(150C, 30 mins) | % | ≤2.5 | ≤1.0 | ≤2.5 | ≤1.0 | ≤2.5 | ≤1.0 | ≤2.5 | ≤1.0 | ≤2.5 | ≤1.0 | ≤2.5 | ≤1.0 | ≤2.5 | ≤1.0 |
| adhesion | N/mm | ≥7.8 | ≥7.8 | ≥7.8 | ≥7.8 | ≥7.8 | ≥7.8 | ≥7.8 | |||||||
| Weight | g/m2 | 305+20 | 360+20 | 450+20 | 530+30 | 630+40 | 780+40 | 860+40 | |||||||
| Thickness | mm | 0.50+0.06 | 0.53+0.06 | 0.62+0.06 | 0.75+0.06 | 0.85+0.09 | 1.07+0.10 | 1.20+0.10 | |||||||
Why choose us?
1.A professional international sales team, which is specialized in the framework materials for 16 years.
2.Well and high-quality control
3. Strong production capacity and testing capabilities
4.Various designs are available
5.Prompt delivery
6.FREE SAMPLE can be offered
7.The products are sold to all larger tyre manufacturer in China and export to many counties and regions in Europe,
South America, Africa ,Middle east, South and east Asia and so on,and enjoy a good reputation.
What 's the capacity?
The Group has production capacity of Canvas Fabric 30,000 tons/year, Steel Cord 100,000 tons/year, Bead Wire 60,000 tons/year
Tyre Cord Fabrics 40,000 Tons / year, Carbon Black 150,000 tons/year , Tyre Liner Fabric 5 million meters/year ,Film 20,000/year.
Shipping Details:
1.International standard export packing in packages or according to t o customer's requirement.
2.Loading port: Qingdao ,Shanghai or according to customer's requirement
3.Delivery Time:
2 -5 days for samples
15-20 days for 1-4 20fcl containers
20-30 days for 3-6 20fcl containers
4.Payment Terms:
Payment: 30% deposit, 70% by T/T against B/L copy or by L/C.
