Hot Sale Automatic Rotary Die Cutting Machine Blank Label

Product Description

Hot Sale Automatic Rotary Die Cutting Machine Blank Label
MQ-320 high quality Paper Label China automatic double head die cutting machine Application: it is used for die cutting adhesive label, adhesive tape products, this machine is best choice working with high speed roll label printing machine, flexo printing machine, satellitic printing machine, PS printing machine, batch-type printing machine. Introduction: this machine is researched by ourselves. it is flat bed structure, computer-servo system pull material. feeding die cutting waste discharge rewinding sheet cutting, all processes are completed by computer in one time.
Feature: 1. adopt english trio system, motion controller, intelligent servo PLC system. 2. aytomatic web guiding system 3. 24000 times/h, 7200m/h die cutting, ensure run fast, high accuracy, working stably. 4. use wood die cutter, cheap and durable. 5. roller automatic inflate, driving system with automatic lubricate system, automatic tension control. 6. it can do vertical and horizontal hot stamping 7. all are imported parts, such as electronic parts, bearing, transducer
Technical Parameters: Model MQ-320 max. feeding width 350mm NO.1 cutting area 350mm*350mm NO.2 cutting area 350mm*350mm Max. speed 24000 times/h Max. length of meter 70m/min Position accuracy +- 0.1mm Max. unwind diameter 800mm Max. rewind diameter 800mm Voltage 380V 3phase Gross power 13kw Dimension 3400*1600*1600mm
