US$26.00-30.00
|
1 Meter
(MOQ)
|
Basic Info.
Material
Eucalyptus, Wood and Rubber
Suitable for
Adult, Adult
Type
Pilot Ladder, Embarkation Ladder, Pilot Ladder
Using Field
Aquatic, Aquatic
Neighboring Step
330+/-20mm
Pilot Ladder Length
Customized
Transport Package
Cover by Plastic
Production Capacity
10000PCS/Month
Product Description
SOLAS standard Marine Embarkation ladder and Pilot Ladder
Product DescriptionPilot ladder and embarkation ladder are one type of rope ladder, usually made by hard wood and used for embarking and disembarking pilots and crew. It is an important tool for marine safety. With spreaders step (Preventer Step) and magnet, pilot ladder and embarkation ladder could work safety under kinds of sea conditions.
Pilot ladder
Standard: SOLAS 1974 as amended, Reg.V/23 and X/3
IMO Res.A.1045(27), IMO MSC/Circ.1428, ISO799(2004)
Embarkation ladder
Standard: SOLAS 1974 as amended, Reg.III/4, III/11, III/34, and X/3;
IMO ResMSC.36(63). (1994 HSC code), IMO Res.MSC.48(66)(LSA code), IMO
Res.97(73)(2000HSC code), IMO Res. MSC.81(70), ISO5489(2008)
Detailed PhotosMade up of Rubber step (the last four steps), Wood step, Spreader (Preventer Step), Step fixing piece, rope.
Rope:
Ropes should be mold-resistant manila or heat-treated polyester rope with polypropylene core and should not be covered. Ropes shall be of a diameter which is no less than 57mm in circumference, and have a braking strength more than 24KN.
Steps: The distance of inner edge of side ropes should be more than 400mm, the width of step is no less than 115mm, and thickness no less than 25mm. The steps should be non-slip, hard wood steps without knot and equally spaced at 330±20mm.
Rubber Step:
The bottom 4 steps may be made f resilient synthetic raw material or rubber if it is of sufficient strength and stiffness. Rubber steps should be of the same required dimensions as the wooden steps.
Spreader:
Spreader shall have the same specifications as normal steps, but length of spreader shall not be less than 1.8 meters.
Step Fixing Piece:
Must be wood or plastic
Fastening Hardware:
Fastening hardware for rope and steps must be corrosion resistant, or made of similar material treated corrosion resistance.
Product Parameters
Name | mm Board Size (mm) | Orifice | Material |
Short Board | Long Board |
Pilots Rope Ladder | 525×115×28 flat board | 1800×115×28 | Φ25mm | willow |
525×115×30∼38 525×115×30∼60 slotting board |
Rope Ladder | 525×115×28 flat board | 1800×115×28 |
525×115×30∼38 525×115×30∼60 slotting board |
Step material: Hard wood
Step spacing: 330+/-5mm(525*115*28mm)
Rubber step qty: The four lowest steps made of rubber plate with steel liner
Long board: 1800*115*30mm
Description | Material | Size |
Shackle | 45#Galvanized steel | Dia.22.5mm |
Thimble | 45#Galvanized steel | Dia.22mm |
Side rope | Manila ropes | Dia.22mm, 3-strands |
Seizing rope | Polyamide anti-aging rope | Dia.4mm, 3-strands |
Step | Aluminium(ELA) Hard wood(ELB) Hard wood(PLB) Rubber(ELA&ELB) | 526*115*46mm 526*115*30mm 1800*115*30mm 526*115*30mm |
Packaging & ShippingWe can pack according to your requirements or according to different situation.
