High Quality and Top Level Bp-1000 Plasma Spray Equipment, Surface Treatment Production Line, Ceramic Powder Coating Machine
Basic Info.
Model NO.
BP-1000
Type
Coating Production Line
Coating
Powder Coating
Substrate
Powder Coating Machine
Certification
CE, ISO
Condition
New
Core Components
PLC/ Spraying Gun
Weight
850kg
Control System
Siemens PLC, 15-Inch Touch Screen
Powder
Ceramic/Metal Alloy
Transport Package
Wood Cases
Specification
control cabinet, spraying gun, powder feeder
Trademark
BP
Origin
China
Production Capacity
200/Year
Product Description
Product DescriptionThis series of Plasma Spraying equipment is designed for thermal spraying Metal, Alloy and Ceramic coating to surface treatment process. Application in spraying or coating the Metal, Oxide, Alloy, Carbide, Nitride, Boride and complex powders on the small parts, large workpiece, Mechanical, project construction and Medical Industry so on. Making the surface to achieve Anti-corrosion, Wear resisting, High Hardness, long-lasting, High Temp. resisting, Oxidation resistance and so on.
Detailed Photos
Product Parameters
BP-1000 Plasma Spraying Equipment Parameters:
| coating material | Metal, Alloy, Oxide, Carbide, Nitride, Boride, Complex powder |
| Mian Gas & Pressure | Nitrogen(0.6Mpa) Argon(0.8Mpa) |
| Secondary Gas & Pressure | Helium (0.4Mpa) |
| Gas Using Type | Argon+Hydrogen Nitrogen+Hydrogen |
| Argon control | 90L MFC |
| Hydrogen control | 20L MFC |
| Powder feeding barrel | 3.0L * 2 |
| Powder feeding velocity | 180g/min |
| Water Chiller Capacity | 200L |
| Power supply | 180KW |
| Spraying Gun power | 60KW |
| Control system | Siemens PLC, touch screen |
| Compressor | American Copeland |
Company Profile
SHANGHAI BIANPU TECHNOLOGY CO.,LTD
We are specialized in production of all kinds of spraying equipment and the technology application for surface coating treatment for over 15 years in China. We provide professional coating technology services and automatic production of turnkey project, such as spraying equipment, spraying soundproof room, spraying auxiliary equipment, manipulators, dust collection and pretreatment sandblasting system. We also supply coating materials like all kinds of spray Powders and Arc spray Wires. Our Company has a group of experienced and professional technicians in coating processing and construction of turnkey projects.
Main Equipment:
Thermal Spraying Equipment( Plasma spraying, HVOF spraying, Arc Spraying), Auxiliary Equipment( Spraying soundproof room, Dust collection system, Rotary table, Six-axis manipulator, Sandblasting system), Automatic production of turnkey project.
Coating Processing Service:
Wear-resistant, High temperature resistance, Anti-corrosion, Insulation, Magnetic inductive, Self-lubricating wear sealing, anti-stick and wear-resistant, repair coating.
Spray Coating Product
Company Ancillary Equipment
Certifications
