Foam Plastic Recycling Machine for PS Material Reuse and Repurpose

Product Description

PS Foam Plastic Recycle Machine
The PS Foam Recycle Machine is the crucial final step in the PS foam production process. This indispensable machine embodies efficiency and sustainability at its core. Waste products are first directed to the powerful crusher, followed by seamless progression to the primary and secondary screws. They are meticulously cooled using both air and water before undergoing precise cutting. Any substandard materials are efficiently discarded, while the majority are carefully stored for future use. Ultimately, these stored materials are fed into the advanced extruder machine, paving the way for the next production cycle.
Machine Features:
- Large silo with an integrated cyclone separator device
- Equipped with a wide inlet grinder and powerful blower; maximum transport distance is 50m - Primary and secondary extruders come with hydraulic screen changers - Features both die-cutting and straight-cutting types
- Effortless operation, stable performance, superior quality, and high automation - Comes with a reducing screw
Model Parameters Unit: HLFSJ-190/130
Capacity kg/h: 300-400
Inlet Width of Grinder mm: 1420
Power of Grinder kw: 30
Max Delivery of Blower m: 50
Power of Blower kw: 5.5
Volume of Silo m³: 9
Diameter of the Primary Screw mm: 190/150
L/D: 21.4:1
Diameter of the Second Screw mm: 130
L/D: 12:1
Installed Power kw: 261
Cooling Water Pressure MPa: 0.3-0.4
Installed Size (LxWxH) m: 20x3.5x6.1
Weight t: 12
