CM772F 3BDH000368R0001

Product Details

Product Description

Product Description
Brand:ABB
Type:CM772F 3BDH000368R0001
Origin: the Swiss
Warranty: 365 days
Colour: new/used
Shipping method: Courier delivery
Spare parts spare parts, the main DCS control system of PLC system and the robot system spare parts,
Brand advantage: Allen Bradley, BentlyNevada, ABB, Emerson Ovation, Honeywell DCS, Rockwell ICS Triplex, FOXBORO, Schneider PLC, GE Fanuc, Motorola, HIMA, TRICONEX, Prosoft etc. Various kinds of imported industrial parts
Al-Profile Support For DIN-Rail Units comprising the AC 800M controller are mounted onto DIN-rails (type: TS 35/7.5). However, the DIN-rail itself is not rigid enough to support the units on its own. For this reason a support is recommended, such as an A1-profile, specifically designed for supporting DIN-rails (see Figure 118 on page 403 and Figure 119 on page 404). Key features of the Al-profile are: • Simple mounting. • No drilling required; profile incorporates pre-formed channels suitable for selftapping screws. • Provides secure mounting in locations subject to extreme vibration, see Figure 18 on page 69. • Rigid construction. • Easy-fit, press-in cable-retaining duct.
General At an ambient temperature of 40°C (104°F) it is considered unnecessary to calculate the heat dissipation requirements for a standard AC 800M Controller with S800 I/O configuration, mounted within ABB floor-mounted or wall-mounted cabinets. For a standard AC 800M Controller configuration housed within a floor-mounted or wall-mounted cabinet, the recommended fuse rating for the external mains supply is: Should the configuration be other than that stated, detailed instructions for calculating current consumptions can be found in the following text. The following tables present current consumption and power dissipation for all relevant hardware units included in AC 800M Controller. Use this information for: • Dimensioning the supply requirements of an AC 800M and S800 I/O configuration. • Calculating cabinet-generated power loss. The values given in the tables are typical and adapted to these applications. It is assumed that 70% of unit channels are active simultaneously.
