Laboratory Cotton Compact Spinning Machine

Product Description

Product Description
Product DescriptionAT211 Laboratory Compact Spinning Machine is part of the mini spinning system. It’s mainly used in university, researching center etc. and it is used to convert roving into yarn. And in the same time, impart strength to the yarn by inserting the necessary amount of twist and then winding the twisting yarn on bobbin or tube. SpecificationModelAT211Spindle number4 or customizedFiber typeCotton, wool or blend fiberCompact spinning structureNegative pressureTwisting range200-2000 twist/mDrafting rangeApprox. 2~50Fiber length22 ~ 51 mm or customizedOutput capacity0.25 ~ 1 kg per hour or customizedRoller diameterΦ25/25/25mmRing diameterΦ38 ~ 45mmRing spindle speed12000rpmPower220V/380V, 50Hz, 550WDimension1200*800*1600mmDetails & Features★ It adopts touch screen and PLC control.★ Imported frequency converter of high efficiency.★ Mini type machine, save researching cost and easy to operate and maintain.★ Can be used for cotton fiber or wool fiber (alternative) with different partsOur CompanyHistorySince 1982 with more than 20 years’ experienceWarrantyTwo Year Warranty for whole productTrainingVideo and user manual for trainingOnsite serviceInstallation and training service is availableTesting serviceFree sample testing before order is availableLead time15 working days lead time for most productPacking & DeliveryPackagingPackaging Details1. The equipment is covered with film is protect it from water vapour during the trip. 2. The box is filled with foam to protect the equipment from impact. 3. Exported wooden box made from plywood, don't need fumigated. PaymentPayment TermT/TEXW30% T/T in advance, paid the balance before shipmentFOBCFR(C&F)30% T/T in advance, paid the balance against copy of B/LCIFL/CL/C amount above 50,000 usd, we can accept L/C at sightWest UnionAmount lower than 5000usdWest UnionDelivery Time7~10days after receiving payment for one containerContacting Us
