Walking Rice Planting Machine Automatic Operated 2zgq-825 Agricultural Rice Transplanter Rows Optional

Product Description

Product Description

High performance
High horsepower engine, low noise, low vibration, low fuel consumption; High heat dissipation efficiency, eliminating high temperature;
Equipped with large capacity fuel tank, effectively reducing the number of refuelling times and improving operational efficiency;
Imitation of manual transplanting design, it is not easy to hurt the seedling when taking the seedling, and the seedling is in good posture and quick to return to the green;
Super strong electronically controlled hydraulic shape imitation system: efficiently identifying the state of the field, real-time matching of the transplanting section, ensuring the quality of transplanting; Extra-large rice-planting capacity: the single rice-planting capacity can meet the operation of 5 mu, reducing the frequency of rice-planting, and efficient operation. High passability
Long wheelbase: excellent axle load distribution of the whole machine, efficient driving;
Wide and large diameter wheels, 500mm high ground clearance, adaptable to all kinds of paddy field operation;
Anti-trapping variable speed function: anti-trapping gear wheel torque increased by 42%, greatly improving the ability to get out of trouble and prevent trapping.

Product Parameters

Product Name				Unit	2ZGQ-825 High Speed Ride-on Rice Transplanter
Structure				/	High-speed ride-on type
Drive type				/	Four-wheel drive
Overall dimensions	L×W×H (transport condition)			mm	3370×2230×1920
	L×W×H (working condition)			mm	3340×2478×1850
	Minimum Ground Clearance			mm	500
	Type			/	National water-cooled 3-cylinder 4-stroke diesel engine
	Output/RPM			kW{PS}r/min	Maximum 17.8{24}/3600
	Starting mode			/	Electric motor starter
Travelling system	wheel	types	Solid rubber wheels	Solid rubber wheels	Solid rubber wheels
			Water skidding wheels	Water skidding wheels	Water skidding wheels
		outer diameter	Front wheel	mm	Φ650
			Rear Wheel	mm	Φ950
	Travelling gears			/	Mechanical + Continuously Variable Speed
	Number of gears				Forward 3, Reverse 3
	Steering mode			/	Hydraulic power steering
insertion site	Insertion mechanism			/	Rotary
	Number of rows				6
	Row spacing			mm	300
	Pitch			mm	100,120,140,160,180,210,240
	Insertion depth			mm	10~55
	Number of transverse pick-ups				11,13,16,20
	Longitudinal picking depth			mm	10~20
	Balance mechanism type			/	electro-mechanical
Operating hourly efficiency				hm2/h	0.2~0.45
Fuel consumption per unit of operating area				kg/ hm2	≤5.2
Seedling conditions	Seedling type			/	Blanket Seedling, Blanket Potting Seedling
	Seedling Height			mm	80~250
	Leaf age				2~4.5
