Stainless Steel Bottle Drinks Sterilization Pot
| US$15,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
TK
Customized
Customized
Certification
CE, FDA, EEC
Scale
Medium
Automation
Automatic
Principle
Rotary
Structure
Tunnel
Operation
Intermittent
Energy
Heat Sterilization
Property
Physical Sterilization
Transport Package
Film Wrapping/Plywood Case
Specification
customized
Trademark
TAIKANG
Origin
Wenzhou City
HS Code
8134000
Production Capacity
100sets/Month
Product Description
Sterilization principle is the use of ultra-high pressure sterilization equipment EHV destroy mold, bacteria organization to maintain food freshness. Food sterilization process is absolutely no heat, add preservatives and other conventional sterilization methods, causing food and nutrition to reduce disadvantage flavor loss. As the state and people's increasing demands for food, processed food by ultra-high pressure equipment is increasingly favored by all walks of life.
EHV sterilization equipment in sealing technology is the key to the whole system is running, the company specializes in the accumulation of a large number of high-pressure technology, vital forces, combined with foreign materials and sealing technology, after several ongoing trial, the company EHV sealing techniques to form a standard, the company has been successfully sealed EHV equipment used in the test equipment, under pressure of 600MPa work very stable.
| Item | Details |
| Equipment size(mm) | 1700X1300X1800 |
| Equipment weight (k g) | 3000 |
| Rated capacity(L) | 2-5 |
| Power Equipment(kw/h) | 12 |
| Start Power Equipment(v) | 380V |
| Pressurization time(s) | 180-280 |
| Parts | touch-screen control system, cooling system, heating system, water treatment systems |
| Media device applications: | Low voltage control 46 # anti-wear hydraulic oil |
| High-pressure system | filtered local tap water |
| MODEL | TK-600/50L | TK-600/100L | TK-600/200L | TK-600/250L | TK-600/300L | TK-600/400L | TK-500/400L |
| MAX.PRESSURE | 600MPa | 600MPa | 600MPa | 600MPa | 600MPa | 600MPa | 400MPa |
| MEDIA SUBSTANCE | Water | Water | Water | Water | Water | Water | Water |
| INNER SIZE | Dia:ø220mm Length:1500mm | Dia:ø260mm Length:2125mm | Dia:ø300mm Length:3030mm | Dia:ø300mm Length:3740mm | Dia:ø320mm Length:3930mm | Dia:ø360mm Length:4300mm | Dia:ø400mm Length:4400mm |
| DEVICE SIZE | 4mX3mX2m (transition belt 6 m) | 5mX3mX2m (transition belt 8 m) | 5.5mX3mX2m (transition belt 10 m) | 6mX3mX2m (transition belt 12 m) | 6mX3mX2m (transition belt 12 m) | 6.5mX3mX2m (transition belt 14 m) | 7mX3mX2m (transition belt 15 m) |
| WIGHT | 25tons | 33tons | 45tons | 55tons | 60tons | 80tons | 90tons |
| PRESSURIZATION TIME | 3-5MIN | 3-5MIN | 3-5MIN | 3-5MIN | 3-5MIN | 3-5MIN | 3-5MIN |
| POWER | 40KW | 80KW | 120KWW | 160KW | 160KW | 240KW | 240KW |
