74 Pneumatic Drilling Machine and Hole-Punching Machine with B16 Spindle Taper

Product Description

Product Description
Characteristic 1. This highly precise drilling machine is a marvel of engineering, designed to be paired with either two-axis or four-axis multi-axis machines, ensuring optimal performance for your drilling needs.
2. Experience the dual benefits of electricity conservation and remarkable efficiency with this machine.

The main technical parameters
Speciflation	SS-74 automatic drilling machine	SS-92 automatic drilling machine
Spindle Taper	B16	B16
Buffer travel	30mm-60mm	30mm-60mm
spindle travel	80mm	80mm
spindle speed	1400-4000	1400-4000
Max drilling capacity	1.5mm-8mm	2mm-16mm
motor power	0.75kw	0.75kw
Number of available multiple shafts	2-4	2-10

Hot Product
Company Information

FAQ
1. Can the drilling machine perform tapping tasks?
No, the primary function of this drilling machine is to create holes.
2. Is the spacing of the machine adjustable?
Yes, it is adaptable to various applications, providing flexible usage.
3. Is the cutting tool prone to breakage?
Under normal operation, the cutting tool is designed to be robust and resistant to breakage.
4: If we need a non-standard machine, what details should we provide?
Please furnish us with the following essential information.
1: A detailed drawing of your product.
2: Samples of your product for reference.
3: Specifications including the product's height, width, and thickness.
4: The maximum and minimum range of the holes required.
5: Information about the material's thickness and width, and the number of drilling and tapping holes needed for your products.
5: Can non-standard machines accommodate both tapping and drilling operations?
YES, they are fully capable of handling both functions.
6. Payment Term
After finalizing the contract, a 40% deposit is required to activate the agreement.
7. Arrange Production
Production commences upon receipt of the deposit. CNC milling machines typically complete in 20 days, while automatic drilling and tapping machines are ready in just 15 days.
8. Packaging
To ensure safe delivery, we highly recommend opting for wooden box packaging to prevent transportation damage.
9. Acceptance Check Upon receiving your goods, meticulously inspect the product: Check for any packing damage, leakage, or item damage; Confirm the product quantity and accessory list match your order; Examine all machine details. Should you notice any issues, capture images and contact us immediately for resolution.
10. Warranty Period
Enjoy a comprehensive one-year warranty. We offer complimentary components within this period if damage is not intentional. Moreover, we provide lifelong maintenance, with parts and shipping costs applicable post-warranty.
We offer on-site debugging and training services. For these services, customers are responsible for covering travel expenses between China and the destination, and must provide accommodation and meals.
The 12-month warranty period starts upon machine arrival. If operational issues arise, our engineers will be dispatched to your location within 24 hours of notification. Post-warranty, we remain committed to maintenance support. Each CNC machine comes with an English manual for maintenance and operation guidance.
11. OEM Service
We welcome purchase orders featuring customers' brands or trademarks, providing customized branding solutions.
