Tyre Recycling System / New High Quality Reclaim Rubber Machine

Product Description

Tyre Recycling System / New High Quality Reclaim Rubber Machine
Processing flow:
rubber powder,coaltar,black rosin ---devulcanizer(after devulcanizing)----rubber mixing mill ----rubber prefiner-----rubber refiner ----reclaimed rubber sheet
Usage:
It adopt new equipment and process of high temperature dynamic desulfidation. In order to reach even and effective desulfidation. We can put pulverous cross linked rubber, softener, activator and water into the pot with heating hermetically and mixing continuously.

Technical details of the machine:
devulcanizer employs a hydraulic system to open, close and lock up the feeding door and the discharging door.
The devulcanizer adopts a new technology of devulcanizition. Compared with tradtional devulcanizing equipments, it is advanced in the following points.
Compared with traditional devulcanizing equipments, it is advanced in the following points:
1) The reclaim powder does not need to be ground so fine;
2) Plastifiers, reclaiming agents and rubber powder can be put together into the devulcanizer;
3) No polluted water will be let out during the devulcanization;
4) The quality is higher;
5) The devulcanizing vessel can be automatically open and close.
FAQ:
1.Q:Are you a factory or trading company?
A:We are factory.
2.Q:Where is your factory?How can i visit ?
A:Our factory located in qingdao city.You can fly to qingdao liuting airport,then we can pick you up to our facotry to visit.Warm welcome visit us.
3.Q:How does your factory control the quality of machines and after sales service?
A:Our machines passed CE,BV,ISO,SGS certification,pls confirm the quality.All our machines have 1 year guarantee, will provide lifetime maintenance.

Product Name	Dynamic desulfurization tank
Model specifications	DTG-Φ1400x3400A
Tank diameter (mm)	1400
Working length tank (mm)	3400
Tank working pressure (Mpa)	2.2
Operating temperature (° C)	230
Heating medium	Superheated steam
Main pressure parts materials	16MnR
Vessel Type	MR-II
Mixing shaft speed (r / min)	11
Main motor power (kw)	18.5
Heating method	Heating oil
