Industrial Equipment Condition Online Wired Monitoring System 8 Vibration and Temperature Integration

Product Description

KMWG series wired monitoring station is used for online monitoring of industrial on-site machine,together with wired sensor they form the core of the monitoring system.It supports access to multiple types of sensors,such as vibration aceleration,vi-bration and temperature sensors,RPM sensors,etc.It also supports synchronous data collection of each channel,and is partic-ularly suitable for condition monitoring and precise fault diagnosis of rotating machine.High-performance signal collection capability to ensure data accuracy, using 24-bit A/D sampling, the highest sampling rate can reach 102.4KSPS, vibration + temperature + RPl synchronous collection.
Flexible data acquisition capabilitysuitable for a variety of collection scenarios, supporting various collection schemes such as timing/ temporary collection, keyphase synchronous collection, speed trigger collection, etc.
Abiity to access multiple sensors, supporting vibration sensorsvibration and temperature sensors, high-freguency resonance sensors, RPM sensors and other sensor types.

Type KMWG-Y16 KMWG-Y8
Vibration temperature measurement	Channels	16 vibration and temperature integration		8 vibration and temperature integration
	Connectable sensor types	ICP Acceleration		ICP Acceleration
	Maximum sampling frequency	102.4kHz		102,4kHz
	Maximum analysis frequency	40kHz		40kHz
	AD conversion	24-bit		24-bit
	Dynamic Range	110db		110db
	Data collection length	1K,2K,4K,8K,16K,32K.64K.128K		1K,2K,4K,8K,16K, 32K,64K,128K
RPM key phase measurement	Channels	2-channel		1-channel
	RPM range	6~30000RPM		6~30000RPM
Communication interface	Ethernet	1		1
	RS485	1		1
Power	power	AC 220V		AC 220V
Construction	Dimension	420*350*120mm		420*350*120mm
	Weight	13kg		13kg
Environment	Operating temperature	-40ºC~+70ºC		-40ºC~+70ºC
	Storage temperature	40ºC~+85ºC		-40ºC~+85ºC
	Humidity	Maxiuen5il		(a coudensation)
	Safety	CE
	Protection	IP66

MODEL	CARTON	ACQUISITION UNIT
KMWG-Y16	420X350X120MM	210X153X35MM
KMWG-Y08	420X350X120MM	210X153X35MM

Dimension
