4m 6m 8m 10m 12m 14m Mobile Type Aluminum Alloy Hydraulic Single Mast One Man Aerial Work Platform Lift

Product Description

Product description:
Aluminum alloy mast lift is mainly made of high-strength aluminum alloy, possessing compact and fine appearance,and the total dimension of the machine is very small and in low weight, so that it can be operated easily and conveniently. With these characters, aluminum lift platform can be carried into narrow spaces passing through doors, corridors and elevators. It is a good assistant for your aerial work and usually used in hotels, supermarkets, airport waiting rooms, museum and gymnasium,etc. for cleaning and repairing.
Technical parameters:

Type	Model	Max Platform Height(m)	Capacity (kg)	Platform Size (mm)	Dimensions (mm)	Power Supply (V/HZ)	Power (kw)	Weight (kg)
Single-mast	RN4-1	4	100	640*580	1200*820*2000	AC220V/50HZ	0.75	250
	RN6-1	6	100	640*580	1200*820*2000	AC220V/50HZ	0.75	280
	RN8-1	8	100	640*580	1300*820*2000	AC220V/50HZ	0.75	300
	RN10-1	10	100	640*580	1400*850*2100	AC220V/50HZ	0.75	350
Double-mast	RN6-2	6	200	1160*540	1400*880*2000	AC220V/50HZ	1.1	450
	RN8-2	8	200	1260*540	1400*880*2000	AC220V/50HZ	1.1	550
	RN10-2	10	200	1360*540	1510*880*2000	AC220V/50HZ	1.1	650
	RN12-2	12	200	1460*540	1610*880*2000	AC220V/50HZ	1.5	700
	RN14-2	14	200	1470*600	1900*1000*2300	AC220V/50HZ	1.5	780

Mainly Features:
1.Emeenrgcy down function, easy to operate, to prevent power outages and accidents.
2.The towbar has a foldable design that is easy to operate and does not take up space.
3.There is a level on the chassis to ensure that the machine is in a horizontal position.
4.The suction cup adjusts the balance legs to provide a solid and stable ground support for the platform.
5.The distribution box is rainproof and equipped with a key.
Detailed images:
company information: Racermax Machinery Co.,Ltd. is mainly manufacturing hydraulic lift, aerial working platform, etc, providing specialized lifting equipment and scheme for both enterprise and privacy .
The main products are : Scissor Lift, Aluminum-alloy mast lift, Four-post Car Lift, Wheelchair Lift, Vertical cargo Lift, Articulated boom lift, Hydraulic dock leveler and other special customized products. Company product design and manufacturing experience in fifteen years, a series of special technology, developing the key technology, through ISO9001 and European quality CE certification,
Racermax formed a special non-standard customized, precision manufacturing and processing of professional technology, has its unique function of products, quality, service, and has integrated index with foreign products can match.
Our commitment is to provide high quality, not only reliable products, but also provides the consummation post-sale service, sincere, let users satisfactory. The company has been widely used product groups: in aviation, nuclear power plants, logistics, hospitals, railway stations, factories, auto 4S stores and other industries.
Parking&shipping
Our services:
1. All the machines will b full tested before shipment.
2. The total machine guarantee for 12 months.
3.24 hours technical support-email, telephone or video online.
4. User-friendly English manual for machine using and maintaining.
After sales:
1. User-friendly English manual for machine installation using and maintenance.
2. One year warranty for whole machine without man-made fault;
3. We will send you parts for free if there are any non-human factors problem during warranty time
4.24-hours technical support by email, telephone or other communication online.
5. We could reply you in 2 hours after received your any questions even on weekend and holiday, engineers are available to your country if necessary.
FAQ: Q1: How about the delivery time?
A: Within 7 working days after we receive all payment.
Q2: What kind of payments do you support?
A: T/T, L/C, Western Union, Paypal, other terms can be discussed.
Q3: What is the MOQ?
A: Generally speaking, the MOQ is 1 set, Different products have different MOQ.
Q4: Can you produce according to customer's requirements?
A: Yes, of course, we are a professional manufacturer, need to tell us the lifting height, load capacity and platform size, we can design according to your requirements.
