Hydraulic Wall Saw Cutting Machine

Product Description

Hydraulic wall saw cutting machine
Product Description Concrete wall saw cutting machine is mainly used for building or old building renovation, reinforcement, change the design.
1.It can cut the door, window or elevator hole and other large area wall cutting.
2.We have manual,semi-automatic and full-automatic three type for your choose
The structure of non-destructive, one-time molding, in addition to the traditional master can avoid the construction of the damage to the structure of the building; drilling round hole way consumption time, material, human, but also can save a lot of rest time and cost.

Brief structure:


Technical parameter:

Model	YG-800	YG-1000	YG-1200
Saw blade diamete	800mm	1000mm	1200mm
Cut depth	320mm	400mm	500mm
Motor power	6150W	6150W	6150W
Cutting efficiency	3-6m/h	3-6m/h	3-6m/h
Voltage	220v	220v	220v
Best use length	100m	100m	100m
Size	1000*1000*800mm	1200*1200*800mm	1400*1400*900mm
Weight	50kg	78kg	98kg
Frequency	50-60Hz	50-60Hz	50-60Hz

The whole set of machine inculdes:
1. one frame with an electric motor, 220V, 50Hz.
(We could customize the motor according to your requirement.)
2. one disk, 800-1200mm or customized.
3. one set of rails, 1.2m*2 pcs.
4. one saw cover.
5. one set of anchors


Product features
1.Reduce the labor intensity, safe and reliable operation
2.with overload protection, powerful, improved cutting capacity and labor productivity.
3.Special mechanical clutch protection device,safety.
4.Long service life, save maintenance cost.


Product Overviews


On site working


Packaging & Shipping


FAQ Q1: How long is your delivery time?
A2: It is according to the model and quantity.
Generally it is 3-5 days if the machines are in stock.
It will be 15-30 days if you want to customize the machines.
Q2: Do you provide samples? Is it free or extra?
A3: Yes, we could offer you the sample machine.
But it's not free. You need to pay for the sample and the cost of freight.
Q3: What is your terms of payment?
A4: Normally 30% T/T as deposit, the balance to paid before shiping or the copy of BL; We accept T/T, Western Union, Money Gram, Paypal, ****** Escrow etc.
