Small Manual Machine Manual Operation Lathe Machine

Product Description

ITEM	CQ6136
MAXIMUM swing diameter over bed	360mm
maximum swing diameter over table	220mm
distance between two centers	750mm
spindle speed	60-2000r/min/8
spindle bore	38mm
spindle type	MT5
chuck size	KZ11-160
z AXIS stroke	630mm
X axis stroke	160mm
tailstock type	MT3
tool size	20/20mm
small toolpost stroke	70mm
longitudinal feed /grade	0.03-0.42mm/r/9
transverse feed/grade	0.011-0.052mm/r/9
metric thread /grade	0.25-9 mm /27
inch thread /grade	72-4T.P.I/33
diameter pitch tread	8-144D.P./30
modulus tread /gread	0.25-3.5M.P./25
motor power	380V/1.5kw
NW./GW.	600/710kg
overall size	1580x680x1200mm

Shandong Linyi Golden Star Machine Tool Co., Ltd.the original linyi machine tool plant, founded in 1965, is a research and development, production and manufacturing mechatronics CNC machine tool products and characteristics of export products for the main business of state-level high-tech enterprises, with annual production of CNC lathe, vertical machining centers, CNC milling machine, engine lathe, multi-purpose machine, surface grinding machine, etc. The comprehensive production capacity of more than Taiwan. The company has passed THE ISO9001 international quality system certification, and enjoys the right to import and export. It is a patent star enterprise in Shandong Province, with provincial enterprise technology center, provincial one enterprise one technology RESEARCH and development center, municipal engineering technology research center and key laboratory of high-grade CNC machine tool enterprises.
The company is the professional and technical personnel education base in Shandong Province, with 32 scientific research personnel, one expert with outstanding contribution and six senior titles enjoying the special allowance of The State Council. At present, the company has 24 national patents and 5 software Copyrights. Presided over the formulation of JBCPZT1319-2019 CNC double-head vehicle industry standard, and participated in the formulation of JB/T8326 CNC Instrument Horizontal Lathe industry standard.
