Accurate Nailing Position Block Wood Pallet Automatic Production Line

Product Description

Accurate nailing position Block Wood Pallet Automatic Production Line Product Description

This is an full automatic assembly/nailing line from Gongyi UT Machinery for Stringer/American pallets, manually feed the wood into machine, and machine will auto nailing the bottom, auto turn the pallets, auto nailing the face, auto stack, and auto convey. Technical Parameters

Tray	American standard tray, European standard tray, customizable special-shaped tray
Nail gun	MAX,stanley,USA
Air pressure	0.8mpa
Nail gun speed	7 times/s
Motor power	2KW servo motor per second
Receiving	Automatic palletizing (hydraulic, pneumatic)
Size	3300 x 3300 x 3000mm (excluding palletizer)

1)Wood Pallet Nailing Machine is mainly used in the production of American standard pallets and national standard pallets.
2)Wood Pallet Making Machine is equipped with a pallet finished product turning and picking device, which has a high degree of automation and a smooth and compact process. It can be equipped with an automatic stacking for one-stop nailing and stacking production.
3)The whole machine adopts fully automatic program, the operating system adopts imported PLC control, the touch screen is simple to operate, the control is convenient, and the nailing position is standard; compared to the domestic conventional production technology, multiple processes are completed at one time, which greatly improves the work efficiency.
4)Adapt to different size requirements,Wood pallet size can be adjusted within 1.3m*1.3m
1. Applicable tray type, European and American tray
2. Maximum size: 1300x1300x150mm (length x width x height)
3. Production efficiency: up to 60 per hour
4. Number of operators: 1
5. Use nailing tools: automatic air nail gun
6. Power consumption: less than 7.5kw
7. Position and type of nailing: each position can hit 2-4 nails
8. Mould: each tray with different size and structure requires two moulds
