High Toughness Epoxy Vinyl Ester Resin for BMC, SMC, Molded Products

Product Description

Vinyl Ester Resin INV-V495Product Description
Properties:
INV-V495 is a high-strength and high-toughness vinyl ester resin that can be thickened with MgO. It can be used together with a low-shrinkage agent to meet the requirements of low shrinkage, high strength, high toughness, high heat resistance and heat aging resistance. It is suitable for BMC and SMC. , Pre-impregnated sheet and other molded products are formed, and the products maintain high strength retention rate and broad-spectrum acid, alkali, solvent and other media corrosion properties at higher temperatures.
Brief introduction:
Epoxy vinyl ester resin is prepared by the chemical reaction of epoxy resin and methacrylic acid through ring-opening addition. It retains the basic segment of epoxy resin, and has the good process performance of unsaturated polyester resin. After curing under suitable conditions, it shows some special excellent properties.
Matters needing attention:
1. The transportation shall comply with the regulations on the transportation and handling of hazardous chemicals in Chapter V of the State Council's "Regulations on the Safety Management of Chemical Hazardous Substances".
2. The product should be stored in a cool place below 25ºC, avoid fire and isolate the heat source.
3. The shelf life is 3 months under the specified storage conditions.
Features:
The standard bisphenol A epoxy vinyl resin is a vinyl resin synthesized by the reaction of methacrylic acid and bisphenol A epoxy resin. It has been dissolved in styrene solution. The specific molecular structure is shown in the figure below.
Product Parameters
Liquid resin properties (25ºC):

Project	INV-V495
Appearance (visual inspection)	brown cloudy liquid
Viscosity (mPa.s)	1500-2500
Acid value (mg KOH/g)	20-30
Solid content	57-63
Storage temperature (ºC)	normal temperature

Physical properties of resin castings:

Project	Test value	Testing method
Tensile strength (MPa)	63	GB/T 2567
Elongation at break (%)	7.0-10.0	GB/T 2567
Bending strength (MPa)	105	GB/T 2567
Impact toughness (KJ/m2)	20	GB/T 2567
Heat distortion temperature (ºC)	90	GB/T 1634

Note: 1) the casting system sample method is implemented according to GB/T 8237;
2) Post-curing treatment of the casting body: room temperature × 24 hours + 100 °C × 3 hours.
Usage:

Suggested recipe	Name	Weight ratio
	INV-V495	100
	Low shrinkage agent	17
	TBPB	2
	Zinc stearate	2
	MgO	2-4
Adjustment Instructions	Adjusting the addition amount of MgO in INV-V495 can adjust the thickening speed and thickening end point viscosity;

Application
INV-V495 Epoxy vinyl ester resin is suitable for BMC and SMC molded products,such as FRP sight rod,FRP helmet,Composite toe caps.
Our Advantages
Recommended Products

Item No.	Gel Time(25ºC)Min	Chemical Category	Features	Application
INV-V411	10-17	Bisphenol A	Excellent construction technology; excellent corrosion resistance, good corrosion resistance to general acids, alkalis, salts and organic solvents; high solid content, excellent mechanical and mechanical properties	Chemical anti-corrosion equipment, engineering, sporting goods, transportation.
INV-V411M	8-18	Bisphenol A	Standard bisphenol A type epoxy vinyl ester resin. Excellent construction technology, excellent corrosion resistance	Widely used in chemical engineering of many chemical media such as acid, alkali, salt, organic solvent and pipes, tanks, towers, tanks, pools in industry.
INV-V411W	20-30	Bisphenol A	Excellent corrosion resistance, combined with performance and cost advantages, with better price/performance ratio	Anticorrosion equipment and engineering in conventional chemical industry.
INV-V411L- GXX	30-120( can be customized)	Bisphenol A	Has lower viscosity, adjustable gel time, lower exothermic peak	Vacuum infusion molding process to prepare composite products, such as boats, wind power fields
INV-V416	8-14		High reactivity, heat resistance, excellent toughness	Rapid pultrusion to prepare rods, cores, pipes and other products
INV-V440	15-55		Low cure shrinkage, pre-acceleration, anti-sag	Preparation of composite molds, or composite products with low shrinkage requirements
INV-V480	----	Mgo Thickening	High reactivity, thickening with magnesium oxide	SMC molding process to prepare battery shells, fan impellers, etc.
INV-V495	----	Mgo Thickening	High toughness, magnesia thickener	Used together with low shrinkage agent, it can prepare products with low shrinkage, high strength, high toughness, high heat resistance and heat aging resistance, etc. It is suitable for BMC, SMC, prepreg and other molded products. e.g. composite toe caps, helmets.
INV-V650	30-60(can be adjusted based on the accelerator content)	Halogen Free Flame Retardant	Halogen-free, in addition to the corrosion resistance of conventional epoxy vinyl ester resins, it also has good flame retardancy. It is an integrated solution product with anti-corrosion and flame retardant properties.	Mainly used in corrosion-resistant equipment with flame retardant requirements, such as wet electrostatic precipitators in thermal power plants, chimneys, etc.
INV-V470	10-30	Phenolic Aldehyde	Phenolic modified epoxy vinyl ester resin, high crosslinking density, HDT=145 ºC, has more excellent heat resistance and corrosion resistance; especially in acid oxidizing environment, it has long-term resistance.	Heavy-duty anti-corrosion fields with strong corrosiveness and high temperature in chemical engineering and industry.
