Used Straight Seam Welded Tube Mill 150*150 with Direct Forms to Square Technology ERW

Product Description

Overview
Basic Info.

Model NO.	150*150mm Direct Forms to Square tube mill	Application	Industry
Type	Pipe Production Line	Product Name	China Factory Price ERW Pipe & Tube Mill
Usage	making steel pipe	Cutting System	Flying saw
Round Pipe Diameter		Pipe /tube Wall Thickness	Max 6mm
Square/Rectangle Size	40*40mm~150*150mm,
Origin	China	Export Port	Jiujiang,Shekou
Advantages		Machine Color	White
HS Code	85152191	Production Capacity

Product Description
Technological Process
Configuration

Num	Details include
1	Uncoiler
2	Horizontal Accumulator
3	Shear and butt-welder
4	Forming welding and sizing machine
5	Solid state high frequency welder machine
6	Cold cutting saw
7	Run-out table
8	Roller/mould

Parameters

Num	Name		Parameters
1	Forming welding and sizing machine	Forming machine	Horizontal-roll stands quantity:9 stands
			Diameter of horizontal shaft:Φ90mm
			Vertical-roll stands quantity:10 stands
			Diameter of vertical shaft:Φ55mm
		Sizing machine	Horizontal-roll stands quantity:10 stands
			Diameter of horizontal shaft:Φ90mm
			Vertical-roll stands quantity:11 stands
			Diameter of vertical shaft:Φ55mm
		Straightening device	Turk's head type:Two set double turk's head type
		Main driven motor	Main driven motor power:90KW
2	saw	Cold cutting saw	Cutting speed:≤30m/min
			Scale accuracy:≤±3mm

Detailed Photos



Product Parameters

Model	Tube O.D.(mm)	Thickness(mm)	Square & Rectangle(mm)	Thickness(mm)
76 machine	Φ32~Φ89	Max 1~4	25X25~60X60	Max 1~4
89 machine	Φ40~Φ102	Max 1~3.5/4	40X40~90X90	Max 1.5~4
114 machine	Φ60~Φ114	Max 1.5~4
127 machine	Φ60/76~Φ127	Max 1~4.5
140 machine	Φ45~Φ140	Max 1~5
165 machine	Φ89~Φ165	Max 2~6
219 machine	Φ114~Φ219	Max 2~8
273 machine	Φ165~Φ273	Max 3~9	80X80~200x200	Max 3~9
325 machine	Φ165~Φ325	Max 3~10
406 machine	Φ219~Φ406	Max 4~12
