Transfer Machine for Air Guns MW6g7z

Product Description

vertical rotary transfer machine for elbow angle valve body with internal thread

Left layout				Middle layout				Right layout
				Station #1 Lolad/Unload
Shape Tool								Shape Tool
Spindle#1,110mm,Taiwan made,Leath			Station #2					Spindle#2,110mm,Taiwan made,Leath			Station #2
Turning motor (servo) 4 KW, " Gtake " China, 2800RPM		Feeding motor (servo) 1 KW less than 2000RMP	Synchronized clamp. Code:CP-40, China made					Turning motor (servo) 4 KW, " Gtake " China, 2800RPM		Feeding motor (servo) 1 KW less than 2000RMP	Synchronized clamp. Code:CP-40, China made
Roughly drilling				Turning				Roughly drilling
Spindle#3,110mm,Taiwan made, Drilling			Station #3	Spindle#3,110mm,Taiwan made,Leath			Station #3	Spindle#3,110mm,Taiwan made, Drilling			Station #3
Turning motor (servo) 4 KW, " Gtake " China, 2800RPM		Feeding motor (servo) 1 KW less than 2000RMP	Synchronized clamp. Code:CP-40, China made	Turning motor (servo) 4 KW, " Gtake " China, 2800RPM		Feeding motor (servo) 1 KW less than 2000RMP	Synchronized clamp. Code:CP-40, China made	Turning motor (servo) 4 KW, " Gtake " China, 2800RPM		Feeding motor (servo) 1 KW less than 2000RMP	Synchronized clamp. Code:CP-40, China made
Threading								Threading
Spindle #4, 110mm.Taiwan made, Threading (Ext)			Station #4					Spindle #4, 110mm.Taiwan made, Threading (Ext)			Station #4
Turning motor (servo) 5KW, " Gtake " China, 2800RPM		Feeding motor (servo) 1 KW (Xinjie" China less than 1200RMP	Synchronized clamp. Code:CP-40, China made					Turning motor (servo) 5KW, " Gtake " China, 2800RPM		Feeding motor (servo) 1 KW (Xinjie" China less than 1200RMP	Synchronized clamp. Code:CP-40, China made
				Drilling
				Spindle#5,110mm,Taiwan made, Drilling			Station #5
				Turning motor (servo) 4 KW, " Gtake " China, 2800RPM		Feeding motor (servo) 1 KW less than 2000RMP	Synchronized clamp. Code:CP-40, China made
				Threading				Threading
				Spindle #6, 110mm.Taiwan made, Threading (Ext)			Station #6	Spindle #7 110mm.Taiwan made, Threading (Ext)			Station #6
				Turning motor (servo) 5KW, " Gtake " China, 2800RPM		Feeding motor (servo) 1 KW (Xinjie" China less than 1200RMP	Synchronized clamp. Code:CP-40, China made	Turning motor (servo) 5KW, " Gtake " China, 2800RPM		Feeding motor (servo) 1 KW (Xinjie" China less than 1200RMP	Synchronized clamp. Code:CP-40, China made

his is a multi-station transfer machine, to work for the multi-spot processing needs, complete the machining of the part within very short cycle time through multi-spindles linkage. This demonstration is showing processing of part for sewing machine, fix a slidable power head to fulfile dual holes machining. Its high cost performance and efficient widely used in the mass-production task, and fit for compact workshop condition. The compact structure and amazing cycle time compare to the normal single CNC turning machine or other boring machine, performing huge advantage. It is much easy to customize to user specific requirement on process of the part, flexibly to set power head according to process conversion. Rotary Transfer Machine 6G8Z for Safty Valves Body And Brass Pipe Fittings Machining

Can fix 7 to 14 spindles, good at machining of brass fittings in filed of brass valves, gas fittings and play a good role of valves body process, make high workpiece ratio. The vertical type of indexing chuck machine combines precision chucks with the indexing accuracy and reliability of the Hirth ring. OEM or customizable are available to customer products specific requirement, supply customer specific solution to their products. The Vertical Rotary Transfer Machine Tools VR-950 fix world leading brand on key components. Machine Basic Parameter

Station Numbers	6Stations
Driving Unit Numbers	7Spindles
Syntronized Clamp Model	CP-40
Driving Head Motor	Full servo
PLC mode	Bus motion Controller
Indexing Table	421-8D
HMI	10"
Spindle Size	D110mm
Total Power	62KW
Machine Foot print area(ovrall size) M	3.5x2.4x2.85meter
Weight(kg)	7000
