90% New Second-Hand Xg 4 Bridges 12 Square Meters Concrete Mixer Truck

Product Description

Product Description
Basic vehicle parameters: It is very helpful for the transportation and pouring of concrete on construction sites: Category Item Unit Parameter Value

Overall Vehicle Parameters	Outline Dimension	mm	15780×2500×4000
Overall Vehicle Parameters	Overall Weight	kg	54000
Chassis	Brand	/	HOWO
Chassis	Model	/	ZZ5546V52MF1B
Chassis	Wheelbase	mm	1950 + 5200 + 1400 + 1500
Engine	Maximum Net Power	kW	397
Engine	Emission Standard	/	China VI

Key advantages:
The main advantages of XCMGs 4-axle 12-cubic-meter HW chassis National 6 product are as follows
1.Powerful Engine and Efficient Emission Standards
• Dual Power EngineThe HOWO series National 6 product line includes TH7,TX,N,etc.,with MC and WP dual power engines,providing strong power.
• National Six Emission StandardsMeet the latest National Six emission standards,which are environmentally friendly and in line with future trends.
2.High-Quality Materials and Durability
• Tank Material5mm Q345 low-alloy manganese plate,special wear-resistant material,increasing the service life of the tank by more than three times.
• Blade MaterialBaosteel 520 4mm alloy steel,with wear-resistant strips added to extend service life.
• Hydraulic SystemEquipped with pure imported hydraulic systems from Germanys Rexroth and Americas Eaton,ensuring stability and durability.
3.Efficient Operation Performance
• Feeding Speed≥3 m³/min,fast feeding to increase work efficiency.
• Discharging Speed≥2 m³/min,fast discharging to reduce waiting time.
• Residual Discharge Rate≤0.5%,ensuring the quality of concrete.
4.Advanced Operation and Control System
• Operation ModeThree-way operation from both sides and the cab,improving operational convenience.
• Safety DeviceEquipped with a spill receiver device to enhance safety.
5.Comfortable Driving Experience
• Luxury CabHOWO H7 flat-top luxury cab,providing a comfortable driving environment.
• Factory Air ConditioningStandard factory air conditioning for improved driving comfort.
6.Strong Service and After-Sales Support
• Service NetworkOver 1200 appointed service stations and 53 regional spare parts centers,providing strong service support.
• Value-Added ServicesThe road vehicle warranty period is 48 months,and the three major assemblies of the engine,transmission,and rear axle are replaced without repair in case of opening.
7.High Adaptability and Multifunctionality
• Special Purpose ChassisThe chassis has strong adaptability and rich configurations,widely used for modifying various special vehicles such as municipal sanitation vehicles,refrigerated vehicles,crane trucks,flatbeds,oil tanks,pump trucks,fire trucks,towing trucks,and cranes.

Detailed Photos
Product photos are taken from the latest condition of each used car. Interested friends can also communicate further!

Product Parameters
Category Item Unit Parameter Value

Overall Vehicle Parameters	Outline Dimension	mm	15780×2500×4000
Overall Vehicle Parameters	Overall Weight	kg	54000
Chassis	Brand	/	HW
Chassis	Model	/	ZZ5546V52MF1B
Chassis	Wheelbase	mm	1950 + 5200 + 1400 + 1500
Engine	Maximum Net Power	kW	397
Engine	Emission Standard	/	China VI
Pumping System	Theoretical Conveying Volume	m³/h	180
Pumping System	Concrete Pumping Pressure	MPa	10.2
Pumping System	Theoretical Pumping Times	Times/min	22 - 24
Pumping System	Delivery Cylinder Diameter × Stroke	mm	φ260×2200
Placing Boom	Reach Height	m	66.1
Placing Boom	Reach Depth	m	48.6
Placing Boom	Slewing Radius	m	60.9
Placing Boom	Slewing Angle	°	±270
Others	Transfer Type	/	S Valve
