Lab Scale Continuous Stenter machine Drying machine

Product Description

Product Description
Product DescriptionAT289C Lab Scale Continuous Stenter is applicable for laboratory simulation of dyeing and finishing process of drying workshop. It can carry out the resin hot melt dyeing baking fixation test, and confirm the formula and technological condition of dyes, auxiliaries and other composition formula. It can also test hand feeling of fabric, dye discoloration and color fastness in order to obtain smooth and correct samples.SpecificationModelAT289CTemperature range20~250℃Temperature accuracy ±1℃Fan motor1/6HP*3 groupsMain motor for chain drive1HPWorking width max. 40cm, adjustableDwelling time 20s~60min adjustable Power supplyAC380V, 50Hz, 18kwDimensions 2410*940*1390mmWeight Approx. 500kgFutures★ It adopts high quality stainless steel with mirror surface which is corrosion-resistant;★ Using two groups of temperature controller with digital display P.I.D regulator; ★ The fabric width is adjustable;★ Feeding method: A, Using pin chain: feeding → dwelling time which is controlled by regulator → cloth drop B, Using pin frame: feeding → dwelling time which is controlled by regulator → stop automatically ★ Equips with a automatic cloth dropping device and vessel for placing the dropped cloth (If use the automatic cloth dropping device, the pin frame can not be used).★ High efficiency, low cost.Packing & DeliveryPackagingSize2410*940*1390mmWeightApprox. 500kgPackaging DetailsThe normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.PaymentPayment ItemT/TEXW 30% T/T in advance, paid the balance before shipmentFOBCFR(C&F) 30% T/T in advance,paid the balance against copy of B/LCIF30% T/T in advance, paid the balance before shipmentFOBCFR(C&F) 30% T/T in advance,paid the balance against copy of B/LCIFL/CL/C amount above 50,000 usd, we can accept L/C at sightWest UnionAmount lower than 50,000usdDelivery Time7~10 days after receiving payment for one containerRelated ProductsHY0143 High Temperature Dyeing MachineHT-3 Lab Bobbin Yarn Dyeing MachineAT293 Lab Sized Yarn Dyeing Machine AT277 Sample Size Garment & Ribbon Dyeing MachineOur CompanyHistorySince 1982 with more than 20 years' experienceWarrantyTwo Year Warranty for whole productTrainingVideo and user manual for trainingOnsite serviceInstallation and training service is availableTesting serviceFree sample testing before order is availableLead time15 working days lead time for most productContacting usLily ChengWebsiteMobile Phone+86 180 5517 3820Whatsapp+86 180 5517 3820Skype 1933039910@qq.comWechat+86 180 5517 3820
