Metal Surface Finishing Polishing Deburring Tumbling Tumbler Vibratory Finishing Machine

Product Description

Product Description
Antron Machinery's AB(B) series vibratory finishing machines are efficient equipment designed for surface finishing of large andheavy machinery parts. Suitable for pre-finishing metal parts such as gearboxes, gear parts and shafts to ensure the parts achievethe required surface finish and characteristics.
High performance and wide use:
Product Parameters
Technical Drawing:
Technical Data:

Model	Volume	Max overall Dimension A MM	Motor installation tube C MM	Process bowl width D MM	Tunnel depth F MM	Machine height H MM	Moter Power KW	Weight KG
AB(B)100	100	1020	470	216	330	860	1.5/2.2	260
AB(B)200	200	1200	625	220	385	915	3	420
AB(B)300	300	1310	620	270	390	900	3.7/5	600
AB(B)400	400	1410	633	320	450	1040	5	850
AB(B)600	620	1820	610	370	490	1140	5.5/7.5	1000
AB(B)900	920	1930	610	560	575	1350	11	1800

Features

Digital process timer Low profile design Wide opening for big size parts Stress relieved and enhanced with blasting Default manual parts media separation Extended separation deck Wear resistant PU lining from Dow Chemicals

Application
Vibratory polishing machine can be applied to the surface polishing, chamfering, deburring, polishing and brightening of various size workpieces in mass production. It does not affect the original dimensional accuracy of the product after treatment. It also can eliminate the internal stress of the parts and provide the surface finish of the product.This lays a good foundation for some products subsequent electroplating, spraying and other surface treatment.
Company Profile

Packaging & Shipping

FAQ

Q1: How Do You Control the Quality of Mass Finishing Machines? A1: We strictly control quality through the following steps: Laser Cutting, Welding, Shot Blasting, PU Casting, Painting, and Testing. We use high-quality raw materials and strictly control every production step. After production, we test all parts, especially the motor operation and PU quality. We promise excellent machine performance and offer a two-year warranty against non-human damage.
Q2: How Do You Control the Quality of Consumables?
A2: Starting from the mixing ratio of raw materials to the sorting of impurities, we have mastered the key points that need attention at each step. The low loss, high grinding capacity, and high polishing ability of the media are our advantages.
Q3: What is Your Lead Time?
A3: We will arrange shipment within 12 days after payment. Products are ready to leave from Shanghai Port or Ningbo Port within 15 days.
Q4: Can You Provide a Sample Finishing Process?
A4: Yes, we offer a free sample finishing process. Mass Polishing does not charge any service fee for sample trials. Please feel free to contact us! Q5: Can You Provide a Cleaning System?
A5: Yes, we also manufacture cleaning systems, also known as wastewater treatment systems.
Q6: Can You OEM the Tumbling Media?
A6: Yes, we offer OEM solutions for tumbling media. Just send us the media sample, and we will make a testing report and discuss it with you. Q7: Can I Reduce the Noise of the Vibratory Finishing Machine?
A7: Yes, we can make a soundproof cover to reduce the noise from the vibratory finishing machine.
Q8: Is It Easy to Operate Your Mass Finishing Machine?
A8: Yes, the machine is very easy to operate, and we will also guide you on how to use it the first time.
Q9: What is Your Mass Finishing Machine Finishing Process Method?
A9: The methods include deburring, polishing, radiusing, degreasing, cleaning, smoothing, fine polishing, mirror polishing, super finishing, isotropic finishing, ball burnishing, derusting, descaling, pickling, etc.
Q10: What is Your Packaging Method?
A10: For machines, strong plywood is used for a single set. For media, 25kgs per woven bag, and 1000kgs per pallet. For compounds, 50kgs or 25kgs per plastic barrel. Q11: What are Your Price Terms?
A11: Mainly FOB, CFR, CIF, EXW, DDU, DAP. If you need delivered prices (DDU, DAP), you may have to wait an additional 1-2 days.
Q12: What is the Nearest Port?
A12: The nearest ports are Shanghai Port and Ningbo Port.
Q13: What is Your Payment Method?
A13: Usually T/T, but we also accept Paypal. We provide all customers with Trade Assurance Order "PQS" Protection (Payment Protection, Quality Protection, Shipping Protection).
Q14: Which Certificates Do You Have?
A14: We hold certifications such as ISO9001:2015, CE, SGS, and provide a Safe Transportation Report.
