Semi-Automatic Spiral Peanut Soybean Sesame Oil Pressing Machine

Product Description

Usage for Palm kernel Oil Press:
Suitable for the small and medium-sized Veg. Oil Factory and individual user, also be used for pre-pressing for the oil extraction plant.
Application:
Our semi automatic oil press machine can process a variety of oil-bearing seeds, including peanut, palm kernel, grape seeds, cottonseeds, flaxseeds, corn germ, rice bran, moringa seeds, soybean, castor beans and more. If you want to know whether our moringa oil press machine can process your raw materials, you can get in touch with us for detailed informaction.groundnut, cashew nut, sesame, walnut, camellia, pine nuts (Peeling most effective),coconut,soybean,rapeseeds,copra,cottonseeds,peanut,sunflower,
tea seed,gendarmerie seeds,rapeseed/canola,peanut kernel,olive,walnut kernel,maize germ,rice bran,teaseed,sallow thron seed,chinaberry seed,rubber seed,china pepper seed,tomato seed,
water melon seed,grape seed,flax seed,Oenothera seed,pepper seed,castor seed,orange seed,
cocoa bean,coffee bean,perilla,almond kernel,peach seedkernel,avocado,sunflower,sacha
inchi,hazelnut,Xanthoceras,Moringa Seeds,Peony Seed,Shea Butter,Camellia oil,Walnut oil,
Safflower seed,perilla seeds,White sesame seeds,AlmondsCastor bean,linseed,sea-buckthorn,Marula,ect.
Main structure of oil press machine:
Feeder: It is composed of feeder, feeder flange, etc.
Pressing cage: It is composed of upper and lower pressing cages, roll bar, pressing rings, cake output ring and pressing screws, etc.
Gear Box: It is composed of gear box, stainless steel cover, clinder gear, driving axis, rolling bearing, triangle belt wheel, etc.
Stand: It is composed of base, stand, screw nut. The base is the basic component for the assembling and installtion of the entire oil mill. In addition to support the whole machine parts, stand also works as a cookie outlet.
Screw Axis: It is composed of screw axis, pressing screw, cake guide ring, press nut, adjusting bolt and planer bearing, etc.
The advantage of oil pressers:
1. High oil rate - Compared with the old equipment, the normal rate of oil can be higher than 2-3 percentage points, the annual economic benefits are considerable.
2. Energy saving - The same output reduces electric power by 40%.
3. Labor savings - Equal production saves labor by 60%, and production can be organized by 1-2 persons.
4. Wide use - It can squeeze peanuts, flax, sesame, rapeseed, sunflower, cottonseed, soybeans and more than 30 kinds of oil crops.
5. Small footprint - It takes 10-20 square meters to be used.
Technical information:

Model	Capacity		Power	Packing size(mm)	Gross weight (kg)
6YL-68	40kg/h	1T/24H	5.5KW	920x390x750	150
6YL-80	100-120kg/h	3T/24H	5.5KW	1540x510x680	370
6YL-90	100-120kg/h	3T/24H	5.5KW	1540x510x680	370
6YL-95	200kg/h	5T/24H	7.5KW	1920x550x765	550
6YL-100	200kg/h	5T/24H	7.5KW	1920x550x765	550
6YL-105	200-230kg/h	5.5T/24H	11KW	2140x550x765	580
6YL-120	250kg/h	6T/24H	15KW	2100x610x785	680
6YL-130-3	300-500kg/h	8-12T/24H	18.5KW	2240x610x815	800
6YL-165	600-800kg/h	15-20T/24H	22-30KW	2290x750x1020 880X750X760	1600
6YL-200	1000kg/h	24T/24H	37KW	2600*1000*2450	2500
