Plastic Pallets High Quality Extrusion Blow Molding Machine
| US$65,000.00-80,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
ABLD150
Making Method of Parison
Extrusion-Blow Molding
Automation
Automatic
Computerized
Computerized
Certification
CE
Application
Drum, Plate, Float, Roadblocks, Medical Bed Board
Max. Product Volume
250L
Clamping Force
1800 Kn
Machine Type
Accumulation Blow Molding Machine
Die Head Number
Single Head Blow Molding Machine
Moog Parison Controll
Available
Servo Motor
Available
Delivery Time
55-60 Working Days
Warranty
12 Month
Screw Diameter
120*2 mm
L/D Ratio
33
Drive Motor
132*2 Kw
Heating Zone with Cooling Fan
6*2 Zone
Output/Capacity
620~840 Kg/Hr(HDPE Particle)
Heating Capacity
36*2 Kw
Transport Package
Film Packing
Specification
ABLD100
Trademark
Dawson
Origin
Zhangjiagang, Jiangsu, China
HS Code
8477301000
Production Capacity
up to Product
Product Description
DAWSON MACHINERY & MOULD GROUP***EXTRUSION BLOW MOLDING MACHINE EXPERT***
Our customers are all around the world.
Vietnam, Australia, Indonesia, Malaysia, Thailand, Sri Lanka, Kazakhstan, Russia, UAE, Saudi Arabia, Malta, Romania, Italy, India, Syria, Ethiopia, Egypt, Sudan, Tunisia, Algeria, Kenya, Nigeria, South Africa, Zimbabwe, Mexico, Guatemala, Ecuador, Colombia, Venezuela, Peru....
Extrusion Blow Molding Machine ABLD150
| extruder | |||
| 1 | Screw diameter | 120*2 mm | |
| 2 | L/D ratio | 33 | |
| 3 | Drive motor | 132*2 Kw | |
| 4 | Heating zone with cooling fan | 6*2 zone | |
| 5 | Output/Capacity | 620~840 Kg/hr(HDPE particle) | |
| 6 | Heating capacity | 36*2 kw | |
| Accumulator Head | |||
| 1 | Accumulator capacity | 70L | |
| 2 | Design | First in and first out | |
| 3 | Heating zone | 6 zone | |
| 4 | Heating capacity | 64 kw | |
| 5 | Max die&pin diameter | 1000mm | |
| 6 | Accumulator push-out stroke measurement | Transducer Italy Gefran | |
| 7 | Extruder stop | Have | |
| CLAMPING UNIT | |||
| 1 | Platen size | 1800X2120 | |
| 2 | Length of mold | 1730-2200mm | |
| 3 | Clamping force | 1800KN | |
| 4 | Close/Open stroke | 1000-2700mm | |
| 5 | Clamping stroke measurement | Transducer Italy Gefran | |
| 6 | Hydraulic valve | Taiwan Hitech | |
| PARISON CONTROL | |||
| 1 | Programmer | JAPAN MOOG | |
| 2 | Servo valve | MOOG | |
| 3 | Servo cylinder | Intergret of die head | |
| 4 | Hydraulic pack | TAIWAN YOSHE Variable Displacement Piston Pumps | |
