Pillow Block Bearing, UC211, UCP211, Ucf211, UCFL211, UCT211, Ucfc211, Ucph211, Ucpa211, Ucha211, Ucfu211, Ucflu211, Ucfa211, Ucfb211

Product Description

Mounted bearings and housings with rolling bearings support a rotating shaft, which can be bolted on a machine frame or any other substructure. There is no need to precisely machine a bearing housing in a surrounding casing. This makes these solutions cost-efficient and easy to use, while providing full rolling bearing performance.

Unit No.				Dimension			mm					Bolt Size	Bearing No.	Housing No.	Weight (kg)
							in.					mm
	d	h	a	e	b	s1	s2	g	w	B	n	inch
SS-UCP201	12	30.2	127	95	38	13	19	14	62	31	12.7	M10	SS-UC201	SP203	0.69
SS-UCP201-8	0.5	1-3/6	5	3-3/4	1-1/2	1/2	3/4	9/16	2-7/16	1.2205	0.5	3/8	SS-UC201-8		0.69
SS-UCP202	15	30.2	127	95	38	13	19	14	62	31	12.7	M10	SS-UC202	SP203	0.69
SS-UCP202-9	9/16	1-3/16	5	3-3/4	1-1/2	1/2	3/4	9/16	2-7/16	1.2205	0.5	3/8	SS-UC202-9		0.69
SS-UCP202-10	5/8												SS-UC202-10		0.69
SS-UCP203	17	30.2	127	95	38	13	19	14	62	31	12.7	M10	SS-UC203	SP203	0.68
SS-UCP203-11	11/16	1-3/16	5	3-3/4	1-1/2	1/2	3/4	9/16	2-7/16	1.2205	0.5	3/8	SS-UC203-11		0.67
SS-UCP204	20	33.3	127	95	38	13	19	14	65	31	12.7	M10	SS-UC204	SP204	0.66
SS-UCP204-12	3/4	1-5/16	5	3-3/4	1-1/2	1/2	3/4	9/16	2-9/16	1.2205	0.5	3/8	SS-UC204-12		0.66
SS-UCP205	25	36.5	140	105	38	13	19	15	71	34.1	14.3	M10	SS-UC205	SP205	0.81
SS-UCP205-13	13/16	1-7/16	5-1/2	4-1/8	1-1/2	1/2	3/4	19/32	2-25/32	1.3425	0.563	3/8	SS-UC205-13		0.85
SS-UCP205-14	7/8												SS-UC205-14		0.83
SS-UCP205-15	15/16												SS-UC205-15		0.82
SS-UCP205-16	1												SS-UC205-16		0.81
SS-UCP206	30	42.9	165	121	48	17	20	17	84	38.1	15.9	M14	SS-UC206	SP206	1.24
SS-UCP206-17	1-1/16	1-11/16	6-1/2	4-3/4	1-7/8	43/64	25/32	21/32	3-5/16	1.	0.626	1/2	SS-UC206-17		1.27
SS-UCP206-18	1-1/8												SS-UC206-18		1.26
SS-UCP206-19	1-3/16												SS-UC206-19		1.24
SS-UCP206-20	1-1/4												SS-UC206-20		1.23
SS-UCP207	35	47.6	167	127	48	17	20	18	93	42.9	17.5	M14	SS-UC207	SP207	1.58
SS-UCP207-20	1-1/4	1-7/8	6-9/16	5	1-7/8	43/64	25/32	45/64	3-21/32	1.689	1.689	1/2	SS-UC207-20		1.64
SS-UCP207-21	1-5/16												SS-UC207-21		1.61
SS-UCP207-22	1-3/8												SS-UC207-22		1.58
SS-UCP207-23	1-7/16												SS-UC207-23		1.55
SS-UCP208	40	49.2	184	137	54	17	20	18	100	49.2	19	M14	SS-UC208	SP208	1.89
SS-UCP208-24	1-1/12	1-15/16	7-1/4	5-13/32	2-1/8	43/64	25/32	45/64	3-15/16	1.937	0.748	1/2	SS-UC208-24		1.93
SS-UCP208-25	1-9/16												SS-UC208-25		1.9
SS-UCP209	45	54	190	146	54	17	20	20	106	49.2	19	M14	SS-UC209	SP209	2.14
SS-UCP209-26	1-8/8	2-1/8	7-15/32	5-3/4	2-1/8	43/64	25/32	25/32	4-11/64	1.937	0.748	1/2	SS-UC209-26		2.24
SS-UCP209-27	1-11/16												SS-UC209-27		2.2
SS-UCP209-28	1-3/4												SS-UC209-28		2.14
SS-UCP210	50	57.2	206	159	60	20	23	21	113	51.6	19	M16	SS-UC210	SP210	2.66
SS-UCP210-29	1-13/16	2-1/4	8-1/8	6-1/4	2-3/8	25/32	29/32	53/64	4-29/64	2.0315	0.748	5/8	SS-UC210-29		2.78
SS-UCP210-30	1-7/8												SS-UC210-30		2.73
SS-UCP210-31	1-15/16												SS-UC210-31		2.68
SS-UCP210-32	2												SS-UC210-32		2.64
SS-UCP211	55	63.5	219	171	60	20	23	23	125	55.6	22.2	M16	SS-UC211	SP211	3.31
SS-UCP211-32	2	2-1/2	8-5/8	6-47/64	2-3/8	25/32	29/32	29/32	4-59/64	2.189	0.874	5/8	SS-UC211-32		3.46
SS-UCP211-33	2-1/16												SS-UC211-33		3.4
SS-UCP211-34	2-1/8												SS-UC211-34		3.35
SS-UCP211-35	2-3/16												SS-UC211-35		3.29
SS-UCP212	60	69.8	241	184	70	20	23	25	138	65.1	25.4	M16	SS-UC212	SP212	4.9
SS-UCP212-36	2-1/4	2-3/4	9-1/2	7-1/4	2-3/4	25/32	29/32	63/64	5-7/16	2.563	1	5/8	SS-UC212-36		5.03
SS-UCP212-37	2-5/16												SS-UC212-37		4.95
SS-UCP212-38	2-3/8												SS-UC212-38		4.88
SS-UCP212-39	2-7/16												SS-UC212-39		1.81
SS-UCP213	65	76.2	265	203	70	25	28	27	150	65.1	25.4	M20	SS-UC213	SP213	5.15
SS-UCP213-40	2-1/2	3	10-7/16	8	2-3/4	63/64	1-3/32	1-1/16	5-29/32	2.563	1	3/4	SS-UC213-40		5.24
SS-UCP213-41	2-9/16												SS-UC213-41		5.15
SS-UCP214	70	79.4	266	210	72	25	28	27	156	74.6	30.2	M20	SS-UC214	SP214	6.2
SS-UCP214-42	2-5/8	3-1/8	10-15/32	8-17/64	2-27/32	63/64	1-3/32	1-1/16	6-9/64	2.9370	1.189	3/4	SS-UC214-42		6.41
SS-UCP214-43	2-11/16												SS-UC214-43		6.31
SS-UCP214-44	2-3/4												SS-UC214-44		6.21

SAMPLES 1. Samples quantity: 1-10 PCS are available.
2. Free samples: It depends on the Model No., material and quantity. Some of the bearings samples need client to pay samples charge and shipping cost.
3. It's better to start your order with Trade Assurance to get full protection for your samples order. CUSTOMIZED The customized LOGO or drawing is acceptable for us. MOQ 1. MOQ: 10 PCS standard bearings.
2. MOQ: 1000 PCS customized your brand bearings. OEM POLICY 1. We can printing your brand (logo, artwork)on the shield or laser engraving your brand on the shield.
2. We can custom your packaging according to your design
3. All copyright own by clients and we promised don't disclose any info.
Thank you very much for taking time to view our company's website. If you are interested in this product, please feel free to contact us. We are always here.
