CE-Approved Excavator 16m Long Arm Kits for PC200/PC220/PC240 (LDB200)
| US$9,500.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
PC200/PC220/PC240
Usage
Excavator Attachemnts
Bucket
Backhoe
Transmission
Hydraulic Transmission
Drive Type
Internal Combustion Drive
Bucket Capacity
0.5m3
Size
Medium-Sized
Certification
CE, ISO9001: 2000
Condition
New
Material
Q345b (Sgc490)
Boom Length
8800mm
Arm Length
7200mm
Max Dig Depth
10800mm
Max. Extensive Scope
15500mm
Max. Dig Height
13000mm
Folding Height
2980mm
Suit Excavator Tonnage
20ton
Extra Counter Weight
No Need
Bucket Sizes
0.5cbm
Transport Package
Bubble Film
Specification
CE, SGS, ISO9001: 2000
Trademark
GD-Haide
Origin
Dongguan City, Guangdong Province
HS Code
843149
Production Capacity
1000set/Year
Product Description
CE-Excavator long reach boomMaterial: Q345B (SGC490)
Total length: 16000mm(boom length: 8800mm, arm length: 7200mm)
Max dig depth: 10800mm
Max. Extensive scope: 15500mm
Max. Dig height: 13000mm
Folding height: 2980mm
Bucket capacity: 0.5m3
Suit Excavator tonnage: 20Ton
Warranty: 12month after installation
Color: same as original machine's color .
CE certification is available
The include parts as following:
Hydraulic pipe and the Lubricant pipe System, 1*Bucket(0.5m3), 1*Bucket cylinder, 1*connect rod, 4*high-pressure hose, 6*pins, Severalshims, installtools, etc
If you need new arm cylinder and counter weight, we also can prepare for you.
We also can customize all kinds of long boom as per your any requirements.
If possible visit china, welcom to our factory have a look. It will be our big pleasure to service for you.
| MODEL | LDB120 | LDB200-1 | LDB200-2 | LDB300 | LDB350-1 | LDB350-2 | LDB450 |
| boom length(mm) | 7100 | 8220 | 10000 | 10000 | 11000 | 12000 | 13000 |
| arm length ( mm) | 5900 | 7160 | 8000 | 8000 | 9000 | 10000 | 11000 |
| Weight(kg) | 3000 | 4000 | 4200 | 5200 | 6000 | 6500 | 7000 |
| Max dig depth(mm) | 9000 | 11340 | 12200 | 12200 | 14500 | 16100 | 18000 |
| Max. extensive scope(mm) | 12500 | 15100 | 17600 | 17600 | 19600 | 21600 | 23600 |
| Max. dig height(mm) | 11300 | 12510 | 13500 | 13720 | 14920 | 16100 | 17300 |
| folding height(mm) | 2900 | 2980 | 3040 | 3210 | 3210 | 3400 | 3400 |
| bucket capacity(m3) | 0.3 | 0.5 | 0.4 | 0.4 | 0.5 | 0.6 | 0.6 |
| Suit Excavator tonnage(ton) | 12 | 20 | 20 | 30 | 35 | 35 | 45 |
