Hot Sale Truck Type 3ton to 5 Ton Diesel Forklift
| US$10,000.00-20,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
CPCD30/35/40
Cab Location
Not Adjustable
Type
Powered Pallet Truck
Power
Diesel Engine
Load Capacity
1T - 5T
Fuel
Diesel
Load center
>500mm
Lift height
3000~5000mm
Condition
New
3ton to 5 Ton Diesel Forklift for Sale
Forklift
Wheel Forklift
Tyre Forklift
Standard Mast
2 Stage, 3m
Slide Fork
Optional
3 Stage Mast
Optional
Engine Brand
Isuzu
Gearbox
Automatic
Lead Time
30 Days
Capacity Range
1.5ton to 10ton
Transport Package
Forklift Assembled in Container
Specification
ISO
Trademark
world
Origin
China
HS Code
84295100
Production Capacity
2000PCS/Year
Product Description
3ton to 5 ton Diesel Forklift for sale (CPCD30)100% AC power
Italy ZAPI or SME controller
FAAM, HOPPECKE battery optional
CE certificate
specifications:
specifications:
| General | Model | CPCD20Z | CPCD25Z | CPCD30Z | CPCD35Z | ||
| Power type | Diesel | Diesel | Diesel | Diesel | |||
| Rated capacity | kg | 2000 | 2500 | 3000 | 3500 | ||
| Load center | mm | 500 | 500 | 500 | 500 | ||
| Dimension | Lift height | mm | 3000 | 3000 | 3000 | 3000 | |
| Free lift height | mm | 110 | 110 | 110 | 110 | ||
| Fork size (LxWxT) | mm | 1070x120x40 | 1070x120x40 | 1070x125x45 | 1070x125x45 | ||
| Fork outside spread (Min./Max.) | mm | 245/1030 | 245/1030 | 255/1100 | 255/1100 | ||
| Mast tilt range (F/R) | deg | 6/12 | 6/12 | 6/12 | 6/12 | ||
| Front overhang | mm | 480 | 480 | 500 | 500 | ||
| Overall dimensions | Length without fork | mm | 2500 | 2570 | 2680 | 2730 | |
| Length with fork | mm | 3610 | 3680 | 3795 | 3845 | ||
| Overall width | mm | 1150 | 1160 | 1210 | 1210 | ||
| Mast lowered height | mm | 2050 | 2050 | 2080 | 2080 | ||
| Mast extended height | mm | 4000 | 4000 | 4110 | 4110 | ||
| Overhead guard height | mm | 2150 | 2150 | 2150 | 2150 | ||
| Turning radius | mm | 2320 | 2380 | 2460 | 2510 | ||
| Performance | Travel speed (No load/Full load) | km/h | 20/18.5 | 20/18.5 | 20/18.5 | 20/18.5 | |
| Lift speed (No load/Full load) | mm/s | 510/450 | 510/450 | 510/450 | 510/450 | ||
| Max. gradeability | % | 20 | 20 | 20 | 20 | ||
| Tires | Tires | Front | mm | 7.00-12-12PR | 7.00-12-12PR | 28x9-15-12PR | 28x9-15-12PR |
| Rear | mm | 6.00-9-10PR | 6.00-9-10PR | 6.50-10-10PR | 6.50-10-10PR | ||
| Tread | Front | mm | 970 | 970 | 1000 | 1000 | |
| Rear | mm | 980 | 980 | 980 | 980 | ||
| Wheelbase | mm | 1650 | 1650 | 1700 | 1700 | ||
| Min. ground clearance (no ldad/full load) | Mast | mm | 160/140 | 160/140 | 160/140 | 160/140 | |
| Frame | mm | 150/130 | 150/130 | 145/125 | 145/125 | ||
