Fixed Air Detector Station Real Time Measurement Pm2.5 Pm10 No No2 So2 CO2 O3 Outdoor Air Quality Monitoring System

Product Description

Product Description
The detector is mainly for real-time online monitoring of X, gamma and neutron rays in radioactive sites, and can be composed of a monitoring controller and multiple detectors. The monitor can communicate with the detector through RS485 bus, and can also monitor the data with some detectors through 4G network to display the dose rate of each detector in real time. At the same time, the monitoring data can be uploaded to the server for remote monitoring.
The product has following characteristics:
♦ Alarm threshold can be set, with acoustic and optical alarm functions.
♦ 24H real-time monitoring.
♦ Through 4G/WiFi network connection service management system, the detector data can be uploaded to achieve remote monitoring.
♦ Historical data stored and shared to cloud service system platforms, and can be export.

Product Parameters Table 2-1 Parameter Table for each monitored gas

Work voltage	DC5V ±1%/DC24V ±1%	Potter rate	9600
Response time	<30S	Detection principle	Electrochemistry
NO2 measurement range / resolution	0-20/0.001ppm	SO2 measurement range / resolution	0-20/0.001ppm
CO measurement range / resolution	0-100/0.001ppm	O3 measurement range / resolution	0-5/0.001ppm
PM1 measurement range / resolution	0-20m g/m3 0.01ug/m3	TSP measurement range / resolution	0-20m g/m3 0.01ug/m3
Vocs measurement range / resolution	0-20/0.001ppm	Digital signal format	Support for 232 / 485 transmission format, 4G transmission
Sampling accuracy	±2%FS	Work humidity	10~95%RH(non-condensation)
Repeatability	±1%FS	Long-term drift	≤ 1%FS/ years
Work temperature	-20-70ºC	Preheat time	30S
Storage temperature	-40-70ºC	Workpressure	86kpa ~106kpa
Work current	≤50mA	Quality warranty period	One year
Service life	Two years	Case material	Aluminum alloy

Table 2-2 Parameter parameter

Execute standards	ISO14644-1(FS209E)AQ/T4268-2015
Technical principles	Light scattering
Grain diameter channel	PM1/PM2.5/PM10/TSP	Power supply	12V-24V
Recreability	≤±2%	Flow speed	1L/min± 5% constant flow
Measurement accuracy	≤±10%	Communication mode	RS485/RS232
Resolution	0.01μg	Communication protocols	Modbus RTU[slave station]
Maximum valid range	20mg/m3	Interface	5 Core Air Plug
Outdoor protection level	IP65	Protection	Have the sensor sheath gas protection
Detection cycle	Default 60s (1-999s adjustable, recommended ≥ 6s)
Use the environment	Temperature: -10ºC~50ºC; humidity: < 85%RH; atmospheric pressure: 86~106kpa
Explosion level	No (optional explosive isolation protection box EXDIIBT4)
Battery	Optional 5200mah built-in lithium battery
System extensibility	Temperature, humidity, combustible gas, oxygen, carbon dioxide, etc

Table 2-3 Parameter Table of MeteorSensor

Name		Specifications and parameters
Weather sensor	Wind sensor	Equipment power supply: 10~30V DC Equipment power consumption: 360°:0.2W Working environment: -20ºC~+ 60ºC, 0%RH~80%RH Measurement range: 0-360 ° measurement Measuring accuracy: ± 1 ° Communication parameters: Default device address 1, Baud rate 4800 Output signal: RS485
	Wind speed sensor	Equipment power supply: 10~30V DC Power consumption of the equipment: 0.1W Wind speed accuracy: ± (0.2+0.3V) m/s V indicates the wind speed Range of measurement: 0~60m/s Resolution: 0.1m/s Start-up wind speed: ≤ 0.2m/s Response time: ≤ 0.5s Communication parameters: Default device address 1, Baud rate 4800 Output signal: RS485
	Temperature and humidity sensor	Temperature range: -40ºC~80ºC Humidity range: 0%~100%RH Temperature accuracy: ± 0.5ºC (25ºC) Humidity accuracy: ± 3%RH (5%RH~95RH,25ºC) Power supply: 10~30V DC PM2.5/PM10 range: 0 ~ 1,000 ug/m³ Operating temperature: -20~+ 60ºC, 0%RH~80RH Output signal: RS485
