Automatic Plastic Can Making Machine

Automatic Plastic Can Making Machine

US$26,000.00-28,000.00 1 Set (MOQ)

Basic Info.

Model NO.
ABLB55II
Making Method of Parison
Extrusion-Blow Molding
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008
Max. Product Volume
1L
Transport Package
Film Packaging
Specification
ABLB55II
Trademark
APOLLO
Origin
China
HS Code
84773000
Production Capacity
5 Set/Sets Per Month

Product Description


High speed blow moulding machine
Model No.: ABLB55II(double station double die head)
This type of blow molding machine ABLB55II can produce bottle, kettle, can, balls etc. The machine is especially designed for producing with material PE, PVC, PP so on. The productive capacity can reach 480~650PCS/hr.
electronic parts

Name

Trader

Micro computer control system

Japanese MITSUBISHI

Temperature Controller

Japanese MITSUBISHI

Auxiliary Relay

OMRON

contactor

Schneider from France

Electric motor

Three phase 220V or 380V

Power Source

TAIWAN MEANWELL

Transducer

TAIDA FROM CHINA
hydraulic parts

Name

Trader

Oil pump

TAIWAN HIGH-TECH

Valve

TAIWAN JINSHUN/YUKEN

Oil pump and connection

TAIWAN JINSHUN/YUKEN

Sealed part

HALLITE
air control system

Name

Trader

Cylinder

AIRTAC

Air Valve

AIRTAC


Technical Parameters: ( ABLB55II )

Max. Product volume

2 liters

Out put capacity

480~700pcs/h

Screw diameter

55mm

Screw L/D ratio

24 L/D

Screw drive power

15 KW

Screw heating capacity

5 KW

No.of heating zone

3 zones

Output of HDPE

60 KG/H

Oil pump drive power

7.5 KW

Clamping force

45 KN

Max.size of mold

148-508mm

Mold stroke

150-500mm

Max.die diameter

140mm

Blowing pressure

0.6 mpa

Air Volume

0.5 M³/MIN

Cooling water pressure

0.3mpa

Water consumption

40 L/MIN

Size of Machine

2.9x1.5x2.5m

Weight of machine

4.5 ton
