Digital Rockwell Hardness Tester with Color Touch Screen

Product Description

Color Touch Screen Digital Superficial Rockwell Hardness Tester DigiRock DS3

Features:

• Half automatic hardness tester except loading initial force and change force knob. Operation is very convenient and fast.
• Color touch screen, displays loading force, indenter type, dwell time, and conversion scale.
• Motorized control loading, dwell and unloading, eliminates error by manual operation.
• Built-in micro processor auto compute max, min, mean and deviation value, resolution is 0.1HR, largely improve accuracy.
• Auto hardness conversion to others scales, no need to check table and improve working efficiency.
• Support Multiple languages, English, Turkish, German, etc. Convenient for local customers operation.
• With 2000 single testing results and 1000 group results. Reviewing results and analysis.
• Optional blue tooth mini printer is available.

Application:

• Cemented carbides, thin steel, and shallow case-hardened steel.
• Thin steel and medium case hardened steel, and pearlitic malleable iron.
• Steel, hard cast irons, pearlitic malleable iron, titanium, deep case hardened steel, and other materials harder than B100.
• Annealed copper alloys, thin soft sheet metals.
• Copper alloys, soft steels, aluminum alloys, malleable iron, etc.
• Malleable irons, copper-nickel-zinc and cupro-nickel alloys.Upper limit G92 to avoid possible flattening of ball.

Specifications:

Commodity	Color Touch Screen Digital Superficial Rockwell Hardness Tester
Model	DigiRock DS3
Code#	811-230
Rockwell Scales	HR15N,HR30N,HR45N,HR15T,HR30T,HR45T
Preliminary Test Force	3kgf(29.42N) Permitted Error:±2.0%
Test Force	147.1N(15kg),294.2N(30kg),441.3N(45kg) Permitted Error:±1.0%
Dwell Time	Adjustable 1-60s
Hardness Indication	5.2" Touch Screen, Resolution:640x480
Resolution	0.1HR
Loading Control	Auto Loading/Dwell/Unloading
Hardness Conversion	HRC,HV,HBS,HBW,HK,HRA,HRD,HR15N,HR30N, HR45N,HS,HRF,HR15T,HR30T,HR45T,HRB
Conversion Standards	ASTM,DIN
Language Option	Chinese, English, German, Portuguese, Turkish, Czech, Korean
Correction Range	-3.0HR to +3.0HR, Step 0.1HR
Data Memory	2000 Single Measuring Result, Curve Analysis, Results Reviewing And Analysis
Data Output	Optional Blue Tooth Mini Printer
Max. Height Of Specimen	175mm
Instrument Throat	165mm
Power supply	AC220V/50Hz;AC110V/60Hz
Dimension(LxWxH)	546 x 182 x 755mm
Packing Dimension	620 x 460 x 870mm
Gross/Net Weight	110Kg/90Kg
Execution Standard	GB/T230.2, JJS Z2245, EN-ISO6508, ASTME-18
