Double Cone Spiral Mixer for Plastic Compounds

Product Description

The Horizontal Ribbon Mixers are expertly crafted for the seamless mixing, stirring, and blending of powders, granular materials, slurries, or viscous substances. Designed with versatility in mind, they can include a liquid spraying system and be customized to user specifications, allowing them to operate under a range of conditions such as vacuum, pressurized, heated, or cooled. This adaptability ensures that mixing and stirring needs are met efficiently across a variety of process conditions. Horizontal ribbon mixers have become indispensable in industries like chemical, pharmaceutical, food, and building materials. They excel at mixing powder with powder, incorporating a small amount of liquid into powder, and blending powder with granules.
The Horizontal Ribbon Mixing Machine is pivotal in the plastic industry. This advanced mixer unit is primarily designed for diverse resins such as polyethylene, polypropylene, and polyvinyl chloride. It excels in ingredient mixing, coloring, drying, and is also perfect for ABS, polycarbonate, and other engineering plastics during pre-molding processes such as drying, mixing, and material handling.
Product Features
1. Cantilever Shaft Structure, designed so that the bearings are not exposed to material contact.
2. The minimal gap between agitator blades and the container wall effectively prevents material build-up.
3. A standardized agitator drive box that guarantees reliable equipment operation and cuts down on maintenance expenses.
4. Easy-Cleaning: Engineered for speedy and comprehensive cleaning between batches;
5. Durable Construction: Constructed with high-quality materials to ensure lasting performance;
6. Wide Application: Perfectly suited for use in pharmaceuticals, food processing, chemicals, and cosmetics industries.
Technical Parameters

Product Model	RX-LDH-0.3	RX-LDH-0.5	RX-LDH-1	RX-LDH-2	RX-LDH-3	RX-LDH-4	RX-LDH-5	RX-LDH-6	RX-LDH-8	RX-LDH-10	RX-LDH-15	RX-LDH-20	RX-LDH-30
Effective Volume (m3)	0.18	0.3	0.6	1.2	1.8	2.4	3	3.6	4.8	6	9	12	18
Maximum Batch Output (kg)	200	300	600	1200	1800	2500	3000	3600	4800	6000	9000	12000	15000
Rotation Speed (r/min)	62	62	49	33	33	27	27	27	22	22	14	14	12
Drive Power (kW)	5.5	7.5	11	15	18.5	22	30	37	45	55	75	90	110
Equipment Weight (kg)	600	900	1200	2000	2500	3500	4000	4500	5000	6000	7500	10500	13000
Length	2280	2670	3140	3860	4460	4950	5280	5530	2100	5610	5820	6300	7000
Width	680	780	980	1200	1300	1400	1550	1560	1720	1750	2000	2350	2600
Height	880	1240	1400	1650	1700	2000	2100	2200	2500	2650	2900	3160	3350

Product Display
Product Structure
Application
The Double Cone Mixer proves its versatility in industries like powder metallurgy, electrical alloys, magnetic materials, battery powders, pearlescent pigments, and beyond, including chemical, medical, and food sectors.
