Durable Lty-3600 Plastic Molding Machine for Thermoplastic Production
| US$50,000.00 | 1 SET (MOQ) |
Basic Info.
Model NO.
LTY-3600
Type
Plastic Product Injection
Structure
Horizontal
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Clamping Way
Hydraulic & Mechanical
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008, GMP, QS
Transport Package
Wrap Film Packing Into The Container
Specification
360T
Trademark
LOYALTY
Origin
China
HS Code
8477101090
Production Capacity
1000sets/Years
Product Description
| Specification | 0 | LTY3600 | ||
| Injection Unit | Unit | A | B | C |
| Screw Diameter | mm | 60 | 65 | 70 |
| Screw L/D Ratio | L/D | 22.8 | 21 | 19.5 |
| Shot Size(Theoretical) | CM3 | 933 | 1095 | 1270 |
| Injection Weight | g | 849 | 996 | 1156 |
| Plasticizing Capacity | G/s | 219 | 187 | 161 |
| Injection Pressure | G/s | 43 | 46 | 55 |
| Injection Rate | Mpa | 181 | 157 | 137 |
| Screw Speed | r/min | 160 | ||
| Clamping Unit | ||||
| Clamping Force | KN | 3580 | ||
| Toggle Stroke | mm | 660 | ||
| Max.Mould Height | mm | 660*660 | ||
| Min. Mould Height | mm | 680 | ||
| Space Between Tie-Bars | mm | 250 | ||
| Ejector Stroke | KN | 180 | ||
| Ejector Tonnage | mm | 102 | ||
| Others | ||||
| Max.Pump Pressure | Mpa | 16 | ||
| Pump Motor Power | KW | 37 | ||
| Heating Power | KW | 16.5 | ||
| Machine Dimensions(LxWxH) | M | 6.8*1.9*2.3 | ||
| Machine Weight(Approximate ) | T | 11 | ||
