CNC Lathe 2000mm CNC Lathe with Rotate Station CNC Lathe Machine with a Turning Tool

CNC Lathe 2000mm CNC Lathe with Rotate Station CNC Lathe Machine with a Turning Tool

US$10,999.00 1 Set (MOQ)

Basic Info.

Model NO.
SL-X
Type
Horizontal Lathe
Processing Accessory
Chuck CNC Lathe
Guide Rail
Inclined Guide Rail
Tool Holder
6
Power Source
Electric
Controlling Mode
CNC
Automatic Grade
Semiautomatic
Setting Mode
Floor-type
Precision
Precision
Certification
CE, RoHS, ISO 9001
Condition
New
Application
Metal
Control Method
Closed-Loop Control
Numerical Control
CNC/Mnc
Performance Classification
Economical CNC Machine Tools
Movement Method
Linear Control, Contour Control
Processing Precision
0.01~0.02(mm), 0.09~0.1(mm)
Max. Length of Workpiece
300mm
Spindle Nose Taper
A2-5
Speed
4000 Rpm
Spindle Motor Power
5.5kw Servo Motor
Collet Type
Hydraulic Collet
Z Axis
300mm
X Axis
900mm
Guideway Type
32mm Taiwan Ball Screw Rod
Z/X Axis
up to 28m/Min
Transport Package
Polyethylene Foam and Wooden Carton Box If Require
Specification
2000mmx1500mmx1900 mm
Origin
China
HS Code
8458110090
Production Capacity
50000pieces/Year

Product Description

CNC Lathe 2000Mm CNC Lathe With Rotate Station CNC Lathe Machine With A Turning Tool
Product Description
The SL-X is a CNC turning and milling machine that provides various possibilities of tooling combinations with a more powerful spindle (7.4 HP). It is the best solution to satisfy the diverse demand for metalworking and the goal to minimize the tool change time.
Features
With high rigidity body structure, the lathe base is FEM analyzed to ensure the superb rigidity and stability of the lathe.
The patented slant bed design increases the X-axis travel to 900mm and Z-axis to 300mm optimizing the lathe size and stability.

Turning, drilling, tapping, and contouring functions can reduce cycle processing and improve production efficiency.
The main spindle has with C-axis function, high speed, high precision, and low vibration which can make the workpiece precise. Each spindle bearing assembly was tested for dynamic balance before installation to ensure high-speed running stability.

Equips with Taiwan 32mm ball screw rod rail and 32mm linear guideway to provide precision and low vibration tool carriage movement. Equips with auto lubrication system to ensure transmission system is smooth and long-lived.

Robust hydraulic collet chuck can hold bars up to φ45mm and single workpieces up to φ350mm. SmartBrain CNC system co-works with quality electrical parts providing operation and durable use.

Standard Configuration
Fully enclosed splash guard with top roof 5.5KW spindle servo motor Telescopic guards for X/Z axes
Spindle speed 4000 rpm, A2-5 Automatic lubrication system Coolant system
CNC Simulation Hydraulic system Coolant tank
Oil separator LED working lamp Electronic handwheel (MPG)
Coolant gun Toolbox and user manuals The tool holder (5 Sets)
Collet (1 Set) C axis

Applications
Competent in handling the turning process with brass, bronze, aluminum, steel, stainless steel, and rigid plastic with bars diameter up to φ45 mm or single workpieces up to φ350mm.
Optional Accessories

End side & Y-Axis Live Tools
(8 tools)
Chain Chip Conveyor Live Tool Device (Single or Double-Shaft)


3-Jaw Hydraulic Chuck With Soft Jaws(5"/6"/8") Servo Turret Polygon Turning

Oil Mist Collector Part Catcher Servo Bar Feeder


FAQ
1: How can I choose machines? A: for the model selection, please send us the drawing of the turning part, and our engineer will evaluate it and provide the suitable configuration of the CNC lathe fit for your needs.2: What are the main products of your company? A: SmartLathe concentrated all its resources to develop successfully the SL series of CNC slant bed lathes including the SL-07, SL-25, SL-36, SL-46, and the CNC Turning-Milling machines to help our customers in the field of prototyping, entry-level business, and the craftsman with a bootstrap budget. 3: Where is our factory located? How can I visit there? A: Our factory is located in Foshan City, Guangdong Province, 528300 China. You are warmly welcome to visit our factory.4: What are the Trade & Payment Terms? A: FOB, CFR, and CIF are all acceptable. T/T,30% initial payment when order,70% balance payment before shipment; Irrevocable LC at sight.5: What's the MOQ? A: 1 set. We will offer you a better price if you order more.6. What is the delivery time? A: The full series of standard models are in stock. For a customized one, it depends.7. Do you have any certificates? A: Yes, our machine is CE-compliant, and our factory is ISO 9001 accredited.8. What is the warranty period? A: The warranty period is generally 13 months after the B/L date.9. Machine installation. A: SmartLathe could assign the technician to the place for the on-site installation if requested by the purchaser.10. Technical Support A: The technical response is available within 12 hours while the solution for the troubleshooting is provided within 48 hours.
11. Demo and Testing A: SmartLathe built a training center for the clients and employees to study the operation of the machine. You are welcome to visit our factory anytime for the machines' demo. Furthermore, we could demo per your drawing of turning parts.
