CNC Milling Machine Cradle Type 5 Axis Vertical Machining Center
| US$1,500.00-10,000.00 | 1 Piece (MOQ) |
Basic Info.
Type
Tool Milling Machine
Object
Tool
Structure
Bed type
Milling Cutter Type
Angle Milling Cutter
Milling Cutter Structure
Indexable Type
Controlling Mode
CNC
Automatic Grade
Automatic
Precision
High Precision
Certification
CE, RoHS
Condition
New
Process Usage
Metal-Cutting CNC Machine Tools, CNC Non-Conventio
Control Method
Closed-Loop Control
Machine Type
Vertical Machine Cneter
Spindle Taper
Bt40
Spindle Speed
8000rpm
Tool Changing Time
7s
Max, Table Load
600kg
Power(W)
7.5/11
X-Axis Travel
500mm
Max Tool Dia.
150mm
Max Tool Length
300m
Max Tool Weight
8kg
No. of Spindles
Single
Weight (T)
5.1 T
Number of Axes
3, 4, 5
Transport Package
Wooden Packages
Specification
1
Trademark
DX Blast
Origin
China
Product Description
PRODUCT DESCRIPTION In milling - unlike metal turning - the workpiece remains stationary and the mobile cutting edges of the CNC machine move to remove the excess material. This type of machining ensures exceptional accuracy and repeatability, even when making very complex parts and componentsModern industry requires the use of increasingly complex parts that can only be obtained with the help of appropriate technologies. CNC milling is a good example of this. By incorporating computer-controlled numerical devices into the processing process, a high level of precision is achieved, resulting in high quality components and complete repeatability.
Due to the exceptional accuracy achieved by CNC machines, they are used primarily to form metal shapes. The most common is steel. It has a high degree of hardness, however that does not interfere with our machines capacity for precise machining. Stainless steel milling also includes related material groups such as austenitic or heat resistant. This range also includes structural steel, hardened steel, spring steel and many more.
A CNC milling machine can easily handle cast iron blocks (white, gray, black), aluminum and its alloys, tungsten, molybdenum or magnesium. It is also possible to mill copper, nickel super alloys or titanium, as well as various types of composites (especially thermoplastic and thermosetting plastics).
| Travel (XYZ) | 520 x 420 x 220 mm (20" x 16.5" x 9") | 1,020 x 830 x 245 mm (40" x 33" x 10") | 1,520 x 1,150 x 245 mm (60" x 45" x 10") | 1,040 x 850 x 270 mm (41" x 33.5" x 11") |
| Spindle | 2kwatt liquid chilled spindle up to 40,000 RPM | Up to 60,000 RPM | Up to 60,000 RPM | Standard 4 kwatt, 1k - 40k RPM, e-25 HSK Collet Upgrade 8 kwatt, 100 - 34k RPM, e-32 HSK Collet |
| Feed | Up to 28 m/min (1,102 in/min) | Up to 22 m/min (866 in/min) | Up to 22 m/min (866 in/min) | Up to 40 m/min (1,574 in/min) - X, Y Up to 28 m/min (1,102 in/min) - Z |
| Tool Changer | 24 stations automatic tool changer | Up to 143 stations automatic tool changer | Up to 143 stations automatic tool changer | 143 tool change capacity |
| Working Area | 500 mm x 400 mm (19.5" x 16") | 1,000 x 700 x 200mm (39" x 27.5" x 7.5") | 1,500 x 1,000 x 200mm (59" x 39" x 7.5") | 1,000 x 700 x 200mm (39" x 27.5" x 7.5") |
| Rotary axis | Optional 4th axis | Optional 4th axis and 5th axis | Optional 4th axis and 5th axis | Optional 4th axis and 5th axis |
| Footprint (W x D x H) | 805 x 1,290 x 1,880 mm (32" x 51" x 74") | 1,740 x 1,740 x 1,950 mm (69" x 69" x 77") | 2,410 x 2,280 x 1,950 mm (95" x 90" x 77") | 3,358 x 1,855 x 2,235 mm (106″ x 73″ x 88″) |
| Weight | approx. 700 kg (1,543 lbs.) | approx. 1,300 kg (2,866 lbs.) | approx. 2,500 kg (5,512 lbs.) | approx. 3,800 kg (8, 378 lbs.) |
