Hz-1500c ESD Surface Earth Resistance Meter Handheld Electric Resistivity Tester

Product Description

Product Description
The Model HZ-1500C Digital Heavy Droop Surface Resistance Tester is designed to measure the impedance or resistance of all conductive, antistatic and electrostatic discharge surfaces in accordance with EOS/ESD, CECC, ASTM and UL test protocols. Easy to use, high quality and reliable, the meter also measures relative humidity and temperature which affect electrical properties.
Product Features
1) Measure impedance, temperature and humidity in accordance with ESD standards, S4.1,S7.1 and S11.11;

2) 103-1012 ohm/cm2 range to test the electrical properties of a wide range of materials;
3) 10 Volt/100 Volt measurement scale, suitable for workbenches and floors as specified in the standard;
4) Plastic meter protection case to prevent damage to the meter;
5) Light weight, only 150Z (425g), easy to carry;
6) LCD digital display, easy to use and convenient to read;
7) Automatic power-off function, prolonging battery life;
8) Automatic zero return to ensure accuracy;
9) Parallel electrode, 5lb weight probe and built-in impedance probe, all conform to ASTM, EOS and CECC standards;
Detailed Photos
Technical Parameters

Digital Heavy Vertical Surface Resistance Tester
Operating voltage	DC10-100V
Battery Life	keep on working 20 hours
Display Accuracy	1/2±1%
Dimension	170X100X40mm
Measuring Range	10³-1012Ω
Instrument Weight	425g
Heavy Drop Weight	2.5±0.2Kg/PC
Measuring Temperature	0ºC-100ºC
Measurement of humidity	10-90%RH
100~999GΩ	1GΩ
1.00~9.99TΩ	10GΩ
10.0~20.0TΩ	100GΩ

Company Profile
Similar Recommendation
FAQ
Q1:Is your company a sales or a manufacturer?
We are an integrated trade and manufacturing company with our own factory.
Q2:If we need to customize our own brand or if there are special requirements for the built-in software of the machine, can it be customized?
Yes, we accept OEM/ODM/OBM and can customize the built-in software of the product according to the customer's special requirements.
Q3:What is the usual lead time? How long can we receive the order after placing it?
In normal circumstances, products in stock can be received within 5 to 7 days via the fastest international express. Other situations may vary depending on the quantity of products ordered, whether there are special customization requirements, and the delivery time chosen.
Q4:How can we ensure that the product will not be damaged during transportation, considering the large size of the product?
We have professional internal and external packaging to ensure the safety and stability of the products during transportation. For fragile or other special parts, we will include an extra set to ensure that the customer can use the product immediately upon receipt.
Q5:How do you handle after-sales service? What if there is a quality problem with the product or if the customer does not know how to operate it?
For quality issues that are not caused by human error, we provide a one-year warranty from the time the product is delivered, and lifetime technical support. Other after-sales issues will be addressed by our professional technical staff within 24 hours. The product comes with a user manual and an operation video.
