Emerson Rosemount 8700 Series Magnetic Flow Meter Accurate and Reliable Flow Measurement

Product Description

Specification

item	value
Warranty	1 year
Customized support	OEM, ODM
Place of Origin	United State
Brand Name	Rosemounte
Model Number	Rosemount- 3051SFP
Operating Environment	Hazardous, Outdoor

Rangedown
Up to 200:1 (14:1 flow turndown)
Measurement Range
Up to 1000 inH2O (2,48 bar) differential, Up to 3626 psia (250,00 bar) absolute, Up to 3626 psig (250,00 bar) gage
Line Size
0.5 to 1.5 in. (15 to 40 mm)
Output
Differential pressure, static pressure, process temperature, scaled variable, mass flow, volumetric flow, energy flow
Communication Protocol
4-20 mA HART®, WirelessHART®, FOUNDATION™ Fieldbus
Process Wetted Material
316 SST
Diagnostics
Basic Diagnostics, Loop Integrity, Process Intelligence, Plugged Impulse Line
Certifications/Approvals
SIL 2/3 certified to IEC 61508 by an independent 3rd party, NACE, hazardous location, see full specs for complete list of certifications
Update Rate
1 sec. to 60 min., user selectable
Power Module Life
Up to 10-year life, field replaceable (order separately)
Wireless Range
Long range (225 m), extended range (800 m), remote (225 m) and high-gain remote (1 km) Features
Designed with built-in flow calculations for direct reporting of fully-compensated mass flow Advanced diagnostics provide diagnostic coverage to detect abnormal process conditions and electrical loop issues Primary element integrated in a meter run for ease of installation Suitable for small line sizes 0.5- 1.5 in. (15 - 40 mm) for optimal flow measurement accuracy and repeatability Callendar-Van Dusen sensor matching improves temperature accuracy enabling best-in-class flow calculations Ultra for Flow performance class enables optimized flow measurement with a ±0.04% of reading accuracy All-welded, SuperModule™ design offers industry-leading accuracy in harsh environments and applications Flowmeters come fully configured, leak-tested and ready to install right out of the box for fast installation Flowmeter technology eliminates unnecessary pipe penetrations for an integrated, trouble-free solution SIL 2/3 certified to IEC 61508 (via 3rd party) and prior-use certificate of FMEDA data for safety installations WirelessHART® technology is secure, cost-effective and delivers >99% data reliability without the cost of wiring SmartPower™ module provides up to 10-year maintenance-free operation and field replacement without transmitter removal
