Dongfeng 5000L Water Fire Fighting Truck/Fire Fighting Vehicle
Basic Info.
Volume
3001-5000L
Emission Standard
Euro 2
Transmission Type
Manual
Payload
20T
Fuel
Diesel
Drive Wheel
4×2
Horsepower
150-250hp
Condition
New
Overall Dimension
7925×2505×3450mm
Carriage Dimension
7570×2490×2750mm
Carriage Type
Option
Wheelbase (mm)
4500
Max. Speed (Km/H)
105
Max. Grade Ability
35%
Kurb Weight (Kg)
8650
Rated Load (Kg)
7000-10000
Engine
6HK1-Tcng40
Drive Brake
Hydraulic Drum
Parking Brake
Cutting-off Air Brake
Auxiliary Brake
Exhaust Brake
Nominal Voltage
24V
Specification
In nude
Trademark
Dong feng
Origin
Shandong, China
Production Capacity
500 Units Per Year
Product Description
Dongfeng 5000L water fire fighting truck/fire fighting vehicle
| Vehicle Model | TWY5160GXFSGQ | Vehicle Brand | ISUZU |
| Overall dimensions | 7925×2505×3450mm | Curb weight | 8650kg |
| Water tank volume | 5000L |
| Chassis parameters | |||||
| Chassis model | QL1160AMFRY | Chassis brand | ISUZU | ||
| Overall dimensions | 7570×2490×2750mm | Wheel base | 4500mm | ||
| Front/rear wheel track | 1960/1855mm | Front/rear suspension | 1335/1735mm | ||
| Approach/departure angle | 15/17° | Maximum speed | 105km/h | ||
| Chassis Manufacturer | QingLing Motors (Group) Co., Ltd. | ||||
| Cab | Configuration | FVR,double rows cab,allowable 3+3 passengers,with air conditioner, central locking, electric windows, USB audio, cab can be flipped. | |||
| Color | Red,other color is optional | ||||
| Engine | Model | 6HK1-TCNG40 | |||
| Emission | Euro 4 | ||||
| Type | 6 cylinders, in-line, 4-stroke,Exhaust gas turbo ,diesel engine | ||||
| Rated power | 240hp | ||||
| Displacement | 7780ml | ||||
| Manufacturer | Isuzu Engine (Chongqing) Co., Ltd. | ||||
| Tire | Size | 10.00R20 | |||
| Number | 6+1 nos | ||||
| Front axle | 6.3 tons | ||||
| Rear axle | 13.0 tons | ||||
| Drive form | 4X2 | ||||
| Suspension | Multi leaf springs | ||||
| Rated voltage | 24V,DC | ||||
| Transmissions | Isuzu MLD six speed transmission,6 speed forward 1 reverse. | ||||
| Steering device | Power assisted steering | ||||
| Steering wheel | Left hand drive | ||||
| Selective configuration | 11.00-20,11.00R20 | ||||
| If there is a slight change in the chassis parameters above,please take the actual product as the standard | |||||
| Upper-Body specification | ||
| Water tank | Volume | 5000L |
| Material | high quality carbon steel plate, anti-rust treatment inside. | |
| Fire fighting pump | Model | Shanghai Rongshen CB10/40 |
| Max working pressure | 1.251Mpa | |
| Max allowable entrance pressure | 0.4Mpa | |
| Flux: | Water 40L/S | |
| Suction depth | ≥ 7m | |
| Suction time | ≤35s | |
| Fire knozzle(1 sets) | Model: | Shandong Yunhu PS40 |
| Range: | ≥ 55m | |
| working pressure | ≤1.0(Mpa) | |
| Horizontal rotation angle | 360 º | |
| color | The whole vehicle is red for fire fighting, there are white in the middle of truck in accordance with the whole truck | |
