Flexo CTP Machine Ecoographix FL-600e Flexo CTP

Product Description

Product Description
EcooGraphix Flexo CTP Machine FL-600E
EcooGraphix Flexo CTP machine is used for label, trade mark or package printing.
It can expose the Heat corrosive film, digital relief printing plate (water-wash),
digital flexo plate (water-wash), digital flexo plate (solvent based), or Thermal PS plate and so on.
Specification

Technical Specification - EcooSetter Flexo FL-600E CTP
Model	FL-600E (EM)
Imaging System	16-channel
Output Speed	1.25m2/h
Max. Breadth	26" x 17" / 680mm x 430mm
Plate Thickness	0.7mm - 1.7mm
Laser Power	High power semiconductor laser diode
Plate Type	Digital relief flexo plate (water-wash), digital flexo plate (water - wash), digital flexo plate (solvent - wash), steel based digital plates (water/ alcohol washable) are applied for EM/SM series
Application	Label and trademark
Resolution	4000dpi
Plate Loading	Manual load and unload
Interface	USB 2.0
Focus adjust	Dynamic auto-focus
Device Size	1088x770x1100mm (W*D*H)
Net Weight	400kg
Power	220V/50Hz, 60Hz, mainframe 1.5KW + Vacuum, 1.1KW
Environment	Recommended:18-30ºC, Humidity:10-80%

Similar EcooSetter Flexo CTP Series

Technical Specification - EcooSetter Flexo CTP Series
Model	FL-600E (EM)	FL-600S (SM)	FL-800E	FL-800S
Imaging System	16-channel	32-channel	16-channel	32-channel
Output Speed	1.25m2/h	2.5m2/h	1.25m2/h	2.5m2/h
Max. Breadth	26" x 17" / 680mm x 430mm	26" x 17" / 680mm x 430mm	30" x 25" / 762mm x 635mm	30" x 25" / 762mm x 635mm
Plate Thickness	0.7mm - 1.7mm	0.7mm - 1.7mm	0.7mm - 1.7mm	0.7mm - 1.7mm
Laser Power	High power semiconductor laser diode
Plate Type	Digital relief flexo plate (water-wash), digital flexo plate (water - wash), digital flexo plate (solvent - wash), steel based digital plates (water/ alcohol washable) are applied for EM/SM series
Application	Label and trademark
Resolution	4000dpi
Plate Loading	Manual load and unload
Interface	USB 2.0
Focus adjust	Dynamic auto-focus
Device Size	1088x770x1100mm (W*D*H)	1088x770x1100mm (W*D*H)	1630x1170x965mm (W*D*H)	1630x1170x965mm (W*D*H)
Net Weight	400kg	400kg	400kg	400kg
Power	220V/50Hz, 60Hz, mainframe 1.5KW + Vacuum, 1.1KW
Environment	Recommended:18-30ºC, Humidity:10-80%
